A word about the organization of this manual
General information covering all displacements of the H1 range is given in the beginning of this manual.
This includes definitions of operating parameters and system design considerations.
The next sections in the book detail the specific operating limitations for each frame and give a full
breakdown of available displacements, features and options.
General description of H1 family hydrostatic pumps
The H1 axial piston variable displacement pumps are of cradle swashplate design and are intended for
closed circuit applications. Flow direction is reversed by tilting the swashplate to the opposite side of the
neutral (zero displacement) position. The flow rate is proportional to the pump input speed and
displacement. The latter is infinitely adjustable between zero and maximum displacement.
The H1 family of closed circuit variable displacement axial piston pumps is designed for use with all
existing Danfoss hydraulic motors for the control and transfer of hydraulic power.
H1 pumps can be used together in combination with other Danfoss pumps and motors in the overall
hydraulic system.
•
Danfoss hydrostatic products are designed with 14 different displacements (cm³ [in³]):
045 053 060 068 069 078 089 100 115 130 147 165 210 250
45.0
[2.75]
53.8
[3.28]
60.4
[3.69]
68.0
[4.15]
69.0
[4.22]
78.0
[4.76]
89.2
[5.44]
101.7
[6.21]
115.8
[7.07]
130.8
[7.98]
147.0
[8.97]
165.0
[10.07]
211.5
[12.91]
251.7
[15.36]
•
Danfoss hydrostatic products are designed with many different pressure, load-life and control
capabilities:
‒
Electric Displacement Control (EDC)
‒
Forward-Neutral-Reverse control (FNR)
‒
Non-Feedback Proportional Electric control (NFPE)
‒
Automotive Control (AC)
‒
Fan Drive Control (FDC)
‒
Manual Displacement Control (MDC)
‒
Control-Cut-Off valve (CCO)
•
High power density where all units utilize an integral electro-hydraulic servo piston assembly that
controls the rate (speed) and direction of the hydraulic flow.
•
Compatible with the Danfoss family of PLUS+1
®
microcontrollers for easy Plug-and-Perform
installation.
•
More compact and lightweight
•
Improved reliability and performance
Go to the website http://www.powersolutions.danfoss.com/literature/ or applicable product catalog to
choose the components that are right for your complete closed circuit hydraulic system.
Basic Information
H1 Axial Piston Pumps, Single and Tandem
Danfoss hydrostatic product family
4 |
©
Danfoss | April 2017 11062168 | BC00000057en-US0602
