Danfoss MAGFLO MAG 3100

73
MAGFLO
â
9. Service
Commissioning
9.4
Coil resistance table
Coil resistance for MAG 1100, MAG 1100 PFA = 98 ohms +/- 4 ohm
Note
On MAG 1100 ½” produced as from May 1999 the coil resistance must be 86 ohm, +8/-4 ohm.
All resistance values are at 7 °F.
The resistance changes proportionally 0.22 %/°F.
Coil resistance
MAG 3100 MAG 3100 W MAG 5100 W
Inches Resistance Size inches Ohms Tolerance Ohms Tolerance
1
/
2
104 15 104 +/- 2 104 +/- 2
1 104 1 104 +/- 2 104 +/- 2
1
1
/
2
92 1 92 +/- 2 92 +/- 2
2 92 2 92 +/- 2 124 +/- 4
2
1
/
2
100 2
1
/
2
100 +/- 2 127 +/- 4
3 94 3 94 +/- 2 126 +/- 4
4 92 4 92 +/- 2 125 +/- 4
5 92 5 92 +/- 2 126 +/- 4
6 94 6 94 +/- 2 116 +/- 4
8 90 8 90 +/- 2 109 +/- 4
10 92 10 92 +/- 2 104 +/- 4
12 100 12 100 +/- 2 108 +/- 4
14 112 14 112 +/- 2 112 +/- 2
16 100 16 100 +/- 4 100 +/- 4
18 108 18 108 +/- 4 108 +/- 4
20 122 20 122 +/- 4 122 +/- 4
24 115 24 114 +/- 4 114 +/- 4
28 128 28 112 +/- 4 112 +/- 4
30 133
32 128 32 127 +/- 4 127 +/- 4
36 131 36 93 +/- 4 93 +/- 4
40 131 40 103 +/- 4 103 +/- 4
44 126
48 130 48 124 +/- 4 124 +/- 4
54 130
60 124
66 133
72 133
78 147
