RS8KE102 | 15
© Danfoss | ADAP-KOOL® | 2018.11
To configure the controller, go to the Setup Options menu and make selections for your instal-
lation. Below is a list of the Setup Options along with their definitions.
OPT Setup Options Function Default Units
C01 Fan Type Select Fan Type – Single Speed, Two Speed or
VariSpeed
VS Fan
C02 Fan Control Open Select fan operation during Open periods –
Continuous or on Demand
Continuous
C03 Fan Control Closed Select fan operation during Closed periods –
Continuous or on Demand
Demand
C04 Fan Proof Select Disable, DI or CT DI
C05 Monitor phase loss Select No or Yes Yes
C06 Cool Stages Select number of cooling stages(0-4) 2
C07 CL1 Stage Size Set size of cooling stage(0.0 – 2000.0) 1000.0
C08 CL1 Stage Type Select RO or AO AO
C09 CL2 Stage Size Set size of cooling stage(0.0 – 2000.0)
C10 CL2 Stage Type Select RO or AO RO
C11 CL3 Stage Size Set size of cooling stage(0.0 – 2000.0)
C12 CL3 Stage Type Select RO or AO RO
C13 CL4 Stage Size Set size of cooling stage(0.0 – 2000.0)
C14 CL4 Stage Type Select RO or AO RO
C15 Heat Reclaim
Stages
Select number of Heat Reclaim Stages(0-4) 2
C16 Aux Heat Stages Select number of Aux Heat Stages(0-4) 2
C17 Use Gas Heat Does Aux Heat use Gas Heat(Yes/No) Yes
C18 Enable Dehumidi-
fication
Enable Dehumidification(Yes/No) Yes
C19 Control Dehumid
on
Select Control Dehumidification with RH sensor
or CalcDP
CalcDP
C20 Reheat Cntl Reheat Control(No, AuxRly,HeatReclaim,Both) HtRclm
C21 Reheat Cntrl
Sensor
Select Reheat Control Sensor(SupplyAir/Zone-
Temp)
SplyAir
C22 Enable Damper Enable Damper using(Disable, DO, or AO) AO
C23 Enthalpy Cntl Enable Enthalpy Control(Yes/No) Yes
C24 Free Cooling Enable Free Cooling(Disable/Enable) Enable
C25 CO2 Option Select CO2 Damper Control(Disable, Monitor,
Control)
Control
C26 Damper Cntrl
Sensor
Select Damper control sensor(SupplyAir/Mixe-
dAir)
SplyAir
C27 Enable HP Valve Enable Heat Pump Valve in None, Heat or Cool
Mode
None
C28 Fan Control De-
mand
For VS Fan, set fan to Off or Min when no
demand
Min
C29 Fan AO Type Select AO Range for Fan(0-5,1-5,0-10,2-
10,Custom)
0-10 vdc
C30 Compr1 AO Type Select AO Range for Cool1(0-5,1-5,0-10,2-
10,Custom)
1-5 vdc
C31 Compr2 AO Type Select AO Range for Cool2(0-5,1-5,0-10,2-
10,Custom)
1-5 vdc
