Danfoss MCX-RTU - Overrides; Manual Operation Overrides

User Guide | MCX-RTU Rooftop
RS8KE102 | 24
© Danfoss | ADAP-KOOL® | 2018.11
OV0 Service > Over-
rides
Function Default Units
OV1 Override Night-
Setback
Override Night Setback – Enables Night
Setback(Off/On)
Off
OV2 Override Title24 Override Title24 – Enables Title24(Off/On) Off
OV3 Override Fan Override Fan(Auto/Override) Auto
OV4 Override Fan % Sets Speed of Fan when in Override(0.0 –
100.0)
0.0 %
OV5 Override Dam-
per
Override DamperAuto/
Off/25%/50%/75%/100%)
Auto
OV6 Override Cooling Override Cooling(Auto/Off/Stg1/Stg2/
Stg3/Stg4/All On)
Auto
OV7 Override Heat
Reclaim
Override Heat Reclaim(Auto/Off/Stg1/
Stg2/Stg3/Stg4/All On)
Auto
OV8 Override Aux
Heat
Override Aux Heat(Auto/Off/Stg1/Stg2/
Stg3/Stg4/All On)
Auto
OV9 Override Time-
out
Override Timeout – Removes override after
so much time (0-30)
0 m
Overrides OV1 and OV2, are used to enable Night Setback and Title24 modes.
Overrides OV3 – OV8 are used to place the specific features (as shown below) in manual opera-
tion. The override value will be displayed by stage, %, OFF, ON, etc. For analog outputs a value of
zero shuts down the feature and 100 will enable 100% of the feature overridden.
Overrides
