3-15 Reference 1 Source
Option: Function:
[32] Ext. Closed Loop
3
3-16 Reference 2 Source
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select the reference input to be used for
the second reference signal.
•
Parameter 3-15 Reference 1
Source.
•
Parameter 3-16 Reference 2
Source.
•
Parameter 3-17 Reference 3
Source.
dene up to 3 dierent reference
signals. The sum of these reference
signals denes the actual reference.
[0] No function
[1] Analog Input 53
[2] Analog Input 54
[7] Pulse input 29
[8] Pulse input 33
[20] * Digital
pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[23] Analog Input
X42/1
[24] Analog Input
X42/3
[25] Analog Input
X42/5
[29] Analog Input
X48/2
[30] Ext. Closed
Loop 1
[31] Ext. Closed
Loop 2
[32] Ext. Closed
Loop 3
3-17 Reference 3 Source
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select the reference input to be used for
the third reference signal.
•
Parameter 3-15 Reference 1
Source.
•
Parameter 3-16 Reference 2
Source.
•
Parameter 3-17 Reference 3
Source.
dene up to 3 dierent reference signals.
The sum of these reference signals
denes the actual reference.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input
X30/11
[22] Analog input
X30/12
[23] Analog Input
X42/1
[24] Analog Input
X42/3
[25] Analog Input
X42/5
[29] Analog Input
X48/2
[30] Ext. Closed Loop
1
[31] Ext. Closed Loop
2
[32] Ext. Closed Loop
3
3-19 Jog Speed [RPM]
Range: Function:
Size
related*
[ 0 -
par. 4-13
RPM]
Enter a value for the jog speed n
JOG
, which
is a xed output speed. The frequency
converter runs at this speed when the jog
function is activated. The maximum limit is
dened in parameter 4-13 Motor Speed High
Limit [RPM].
See also parameter 3-11 Jog Speed [Hz] and
parameter 3-80 Jog Ramp Time.
Parameter Descriptions Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 61
