Character posi-
tion
Code
Description
AJ
AC socket+cabinet light + extended I/O terminals + motor heater control + insulation monitor
AK
AC socket+cabinet light + extended I/O terminals + cabinet heater + motor heater control + insulation
monitor
AP
Extended I/O terminals + cabinet heater
AQ
Extended I/O terminals + motor heater control
AR
Extended I/O terminals + insulation monitor
AS
Extended I/O terminals + cabinet heater + motor heater control
AT
Extended I/O terminals + cabinet heater + insulation monitor
AU
Extended I/O terminals + cabinet heater + motor heater control + insulation monitor
AV
Extended I/O terminals + motor heater control + insulation monitor
The extended I/O terminal option includes 25 control terminals (-XDW) in the control compartment for use by the customer. If the
enclosed drive is configured with any option C1 card, the -XDW terminal block is used for the option C1 card wiring.
5.7.6.6 Cabinet Heater
Table 59: Auxiliary Function Type Codes
Character posi-
tion
Code
Description
23–24
A3
Cabinet heater
AB
AC socket + cabinet light + cabinet heater
AE
AC socket + cabinet light + extended I/O terminals + cabinet heater
AH
AC socket + cabinet light + extended I/O terminals + cabinet heater + motor heater control
AI
AC socket + cabinet light + extended I/O terminals + cabinet heater + insulation monitor
AK
AC socket + cabinet light + extended I/O terminals + cabinet heater + motor heater control + insula-
tion monitor
AL
AC socket + cabinet light + cabinet heater + motor heater control
AM
AC socket + cabinet light + cabinet heater + insulation monitor
AN
AC socket + cabinet light + cabinet heater + motor heater control + insulation monitor
AP
Extended I/O terminals + cabinet heater
AS
Extended I/O terminals + cabinet heater + motor heater control
AT
Extended I/O terminals + cabinet heater + insulation monitor
AU
Extended I/O terminals + cabinet heater + motor heater control + insulation monitor
AW
Cabinet heater + motor heater control
A8
Cabinet heater + insulation monitor
AY
Cabinet heater + motor heater control + insulation monitor
AQ262141314214en-000301 / 130R0880 | 91Danfoss A/S © 2021.11
Electrical Installation
VLT® HVAC Drive FC 102
Operating Guide
