PVEP
Connector Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6
1x6 DEU PWM_A Error PWM_B Udc GND
PVED-CC
Connector Pin 1 Pin 2 Pin 3 Pin 4
2x4 AMP (A/B) CAN_L Udc GND CAN_H
2x4 DEU (A/B) CAN_H CAN_L Udc GND
PVE Series 5 Connectors
PVED-CC
Connector Pin 1 Pin 2 Pin 3 Pin 4
2x4 AMP (A/B) CAN_L Udc GND CAN_H
2x4 DEU (A/B) CAN_H CAN_L Udc GND
Connector diagrams
1x4 DEU
2
3
4
1
1x6 DEU
1
2
3 4
5
6
2x4 DEU
3
4
1
2
1
2
3
4
A
B
1x4 DIN
1 2
3
4
1x4 AMP
2418
1
2
3
4
1x6 AMP
1
2
34
5
6
2x4 AMP
1
2
3
4
Service Manual
PVG 32 Proportional Valve Group
PVG 32 Component Troubleshooting
©
Danfoss | February 2017 11039167 | AX00000031en-US0301 | 41
