Danfoss TP5000 + RF Installation Instructions

3
Installation Instructions
Important note RF products: Ensure that there are no large metal objects, such as boiler cases
or other large appliances, in line of sight between the transmitter and receiver as these will
prevent communication between thermostat and receiver.
Product Specifi cation
Please Note:
This product should only be installed by a qualifi ed
electrician or competent heating installer and should be
in accordance with the current edition of the IEEE wiring
regulations.
Thermostat features TP5000 TP5000-RF
Power supply 2 x AA/MN1500/LR alkaline cells
Memory back-up 1 min for battery change
Switching action of output relay
1 x SPDT, Type 1B N/A
Switch rating of relay contact 3(1)A, 10-230Vac N/A
Transmission frequency (RF model) N/A 433.92MHz
Transmitter range (RF model) N/A 30m max
Temperature range 5-30°C
Dimensions, mm 110 wide, 88 high, 28 deep
Design standard EN60730-2-9 (EN300220 for RF)
Rated impulse voltage 2.5Kv
Ball hardness test 75°C
Control pollution situation Degree 2
Temperature accuracy ±1°C
Time accuracy ±1 min.
Installation Instructions
GB

Danfoss TP5000 + RF Specifications

General

Type	Programmable Room Thermostat
Display	LCD
Power Supply	2 x AA batteries
Radio Frequency	868 MHz
Frost Protection	Yes
Backlight	No
Communication	Wireless (RF)
Number of Programs	6 programs per day
Wireless Range	30 meters (indoors)
Temperature Control Accuracy	+/- 0.5°C
Programming	7-day or 5/2-day programming
