Danfoss VLT 2800 Quick Guide

Parameter Overwiev
0-XX Operation/Display 0-01 Language *[0] English [1] German [2] French [3] Danish [4] Spanish [5] Italian002 Local/Remote Operation *[0] Remote operation [1] Local operation 003 Local Reference If par. 013 = [1] or [2]: 0 - f
MAX
, *50 Hz
If par. 013 = [3] or [4]: Ref
MIN
- Ref
MAX
, *0.0
004 Active Set-up [0] Factory Set-up *[1] Set-up 1 [2] Set-up 2 [3] Set-up 3 [4] Set-up 4 [5] Multi Set-up 005 Programming Set-up [0] Factory Set-up *[1] Set-up 1 [2] Set-up 2 [3] Set-up 3 [4] Set-up 4 *[5] Active Set-up 0-06 Set-up Copying *[0] No copying [1] Copy to Set-up 1 from # [2] Copy to Set-up 2 from # [3] Copy to Set-up 3 from # [4] Copy to Set-up 4 from # [5] Copy to all set-ups from # 007 LCP Copy *[0] No copying [1] Upload all parameters [2] Download all parameters [3] Download size-independent parameters
008 Display Scaling of Output Frequency 0.01 - 100.00, *1.00 009 Large Diplay Readout [0] No readout [1] Resulting reference [%] [2] Resulting reference [unit] [3] Feedback [unit] *[4] Frequency [Hz] [5] Output frequency x scaling [6] Motor current [A] [7] Torque [%] [8] Power [kW] [9] Power [HP] [11] Motor voltage [V] [12] DC link voltage [V] [13] Thermal load motor [%] [14] Thermal load [%] [15] Running hours [Hours] [16] Digital input [Bin] [17] Analog input 53 [V] [19] Analog input 60 [mA] [20] Pulse reference [Hz] [21] External reference [%] [22] Status word [Hex] [25] Heatsink temperature [°C] [26] Alarm word [Hex] [27] Control word [Hex] [28] Warning word [Hex] [29] Extended status word [Hex] [30] Communication option card warning [31] Pulse count 010 Small Display Line 1.1 See par. 009. *[17] Analog input 53 011 Small Display Readout 1.2 See par. 009. *[6] Motor Current [A] 012 Small Display Readout 1.3 *See par. 009. *[3] Feedback [unit]
013 Local Control [0] Local not active [1] Local control and open loop without slip com- pensation [2] Remote-operated control and open loop without slip compensation [3] Local control as par. 100 *[4] Remote-operated contorl as par. 100014 Lo- cal stop [0] Not active *[1] Active 015 Local Jog *[0] Not active [1] Active 016 Local Reversing *[0] Not active [1] Active 017 Local reset of Trip [0] Not active *[1] Active 018 Lock for Data Changes *[0] Not locked [1] Locked 019 Operating Mode at Power-up, Local Op- eration [0] Auto re-start, use saved reference *[1] Forced stop, use saved reference [2] Forced stop, set ref. to 0 020 Hand Operation *[0] Not active [1] Active 024 Userdefined Quick Menu *[0] Not active [1] Active 025 Quick Menu Set-up Value 0 - 999, *000
Load and Motor 100 Configuration *[0] Speed control, open loop
[2] Speed control, closed loop [3] Process control, closed loop 101 Torque Characteristic *[1] Constant torque [2] Variable torque low [3] Variable torque medium [4] Variable torque high [5] Variable torque low with CT start [6] Variable torque medium with CT start [7] Variable torque high with CT start [8] Special motor mode 102 Motor Power P
M,N
0.25 - 22 kW, *Dep. on unit 103 Motor Voltage U
M,N
For 200 V units: 50 - 999 V, *230 V For 400 V units: 50 - 999 V, *400V 104 Motor Frequency f
M,N
24 - 1000 Hz, *50 Hz 105 Motor Current I
M,N
0.01 - I
MAX
, Dep. on motor
106 Rated Motor Speed 100 - f
M,N
x 60 (max. 60000 rpm), Dep. on par. 104
107 Automatic Motor Tuning, AMT *[0] Optimisation off [1] Optimisation on 108 Stator Resistance R
S
0.000 - x.xxx Ω, *Dep. on motor 109 Stator Resistance X
S
0.00 - x.xx Ω, *Dep. on motor 117 Resonance Damping OFF - 100% *OFF% 119 High Start Torque 0.0 - 0.5 s * 0.0 s 120 Start Delay 0.0 - 10.0 s * 0.0 s
1 Quick Guide VLT 2800 Quick Guide
22 MG.28.M1.02 - VLT
®
is a registered Danfoss trademark
1
