According to international
standards
Type 2840 2855 2875 2880 2881 2882
Output current I
INV.
[A] 9.1 12 16 24 32.0 37.5
(3 x 380-480V)
I
MAX
(60s) [A] 14.5 19.2 25.6 38.4 51.2 60.0
Output power (400
V)
S
INV.
[KVA] 6.3 8.3 11.1 16.6 22.2 26.0
Typical shaft out-
put
P
M,N
[kW] 4.0 5.5 7.5 11.0 15.0 18.5
Typical shaft out-
put
P
M,N
[HP] 5.0 7.5 10.0 15.0 20.0 25.0
Max. cable cross
section, motor
[mm
2
/AWG]
4/10 4/10 4/10 16/6 16/6 16/6
Input current I
L,N
[A] 8.1 10.6 14.9 24.0 32.0 37.5
(3 x 380-480 V)
I
L,MAX
(60s)[A] 13.0 17.0 23.8 38.4 51.2 60
Max. cable cross
section, power
[mm
2
/AWG]
4/10 4/10 4/10 16/6 16/6 16/6
Max. pre-fuses IEC/UL [A] 20/20 25/25 25/25 50/50 50/50 50/50
Efficiency [%] 96 96 96 97 97 97
Power loss at
100% load
[W] 200 275 372 412 562 693
Weight [kg] 3.7 6.0 6.0 18.5 18.5 18.5
Enclosure type IP20 IP20 IP20 IP20/
NEMA 1
IP20/
NEMA 1
IP20/
NEMA 1
1.11 General Specifications
Mains supply (L1, L2, L3):
Supply voltage VLT 2803-2840 220-240 V (N, L1) 1 x 220/230/240 V ±10%
Supply voltage VLT 2803-2840 200-240 V 3 x 200/208/220/230/240 V ±10%
Supply voltage VLT 2805-2882 380-480 V 3 x 380/400/415/440/480 V ±10%
Supply voltage VLT 2805-2840 (R5) 380 / 400 V + 10 %
Supply frequency 50/60 Hz ± 3 Hz
Max. imbalance on supply voltage ± 2.0% of rated supply voltage
True Power Factor (λ) 0.90 nominal at rated load
Displacement Power Factor (cos φ) near unity (> 0.98)
Number of connections at supply input L1, L2, L3 2 times/min.
Max. short-circuit value 100,000 A
See Special Conditions section in the Design Guide
Output data (U, V, W):
Output voltage 0 - 100% of supply voltage
Output frequency 0.2 - 132 Hz, 1 - 1000 Hz
Rated motor voltage, 200-240 V units 200/208/220/230/240 V
Rated motor voltage, 380-480 V units 380/400/415/440/460/480 V
Rated motor frequency 50/60 Hz
Switching on output Unlimited
Ramp times 0.02 - 3600 sec.
Torque characteristics:
Starting torque (parameter 101 Torque characteristic = Constant torque) 160% in 1 min.
*
Starting torque (parameter 101 Torque characteristics = Variable torque) 160% in 1 min.
*
Starting torque (parameter 119
High starting torque
) 180% for 0.5 sec.
Overload torque (parameter 101 Torque characteristic = Constant torque) 160%*
Overload torque (parameter 101 Torque characteristic = Variable torque) 160%*
Percentage relates to frequency converter's nominal current.
* VLT 2822 PD2 / 2840 PD2 1 x 220 V only 110% in 1 min.
VLT 2800 Quick Guide 1 Quick Guide
MG.28.M1.02 - VLT
®
is a registered Danfoss trademark
29
