Danfoss VLT 6000 User Manual

VLT
®
6000 HVAC
23
MG.60.G2.02 - VLT is a registered Danfoss Trademark
{33} LOCK PANEL
Note 5
OPEN -- -- -- -- LOCK OPEN R/W 12-15 LDO
{34} SEL HND.AUTO HAND -- -- -- -- AUTO HAND R 532-13 LDI
{35} RUN ENABLE OFF -- -- -- -- ON OFF W Cmd-6 LDO
{36} BUS TIME 60 SEC 2 2 32767 -- -- R/W 565 LAO
{37} BUSTIME FUNC 0
Note 6
-- 1 0 255 -- -- R/W 566 LAO
{38} F OUT LOW
Note 3
0 HZ 0.1 0 16383 -- -- W 201 LAO
{39} F OUT HIGH
Note 3
Note 4 HZ 0.1 0 16383 -- -- W 202 LAO
Physical Output Points
{40} RELAY OUT 1 OFF -- -- -- -- ON OFF W Cmd-11 LDO
{41} RELAY OUT 2 OFF -- -- -- -- ON OFF W Cmd-12 LDO
{42} PI STRT FR. 0 HZ 0.1 0 16383 -- -- R 422 LAI
{43} RELAY 1 STA OFF -- -- -- -- ON OFF R 530-11 LDI
{44} RELAY 1 STA OFF -- -- -- -- ON OFF R 530-12 LDI
{45} CURR. LIM.S Note 4 A 0.1 0.1 16383 -- -- R 215 LAI
{46} F OUT LOW.S 0 HZ 0.1 0 16383 -- -- R 201 LAI
{47} F OUT HIGH.S Note 4 HZ 0.1 0 16383 -- -- R 202 LAI
{48} REF MIN.S 0 UNIT 0.1 -1638.3 32767 -- -- R 204 LAI
{49} REF MAX.S Note 4 UNIT 0.1 -1638.3 32767 -- -- R 205 LAI
Setpoint Related Points
{50} REF MIN
Note 3
0 UNIT 0.1 -1638.3 32767 -- -- W 204 LAO
{51} REF MAX
Note 3
Note 4 UNIT 0.1 -1638.3 32767 -- -- W 205 LAO
{52} REF STAT OFFREF -- -- -- -- ON.REF OFFREF R 527-8 LDI
{53} BUS REF 0 -- 1 0 32767
Note 7
-- -- R/W -- LAO
{54} SLEEP FREQ.S 0 HZ 0.1 0 16383 -- -- R 404 LAI
{55} WAKEUP FRQ.S Note 4 HZ 0.1 0 16383 -- -- R 405 LAI
{56} SLEEP TIME 301 SEC 1 0 511 -- -- R 403 LAI
{57} SLEEP FREQ
Note 3
0 HZ 0.1 0 16383 -- -- W 404 LAO
{58} WAKEUP FREQ
Note 3
Note 4 HZ 0.1 0 16383 -- -- W 405 LAO
{59} SLEEP MODE OFF -- -- -- -- SLEEP OFF R 532-3 LDI
PI Loop Related Points
{60} INPUT REF 0 UNIT 0.1 -1638.3 32767 -- -- R 510 LAI
{61} PI STRT FREQ
Note 3
0 HZ 0.1 0 16383 -- -- W 422 LAO
{62} PI FEEDBACK 0 UNIT 0.1 -1638.3 32767 -- -- R 511 LAI
{63} PI GAIN 0.3 -- 0.01 0 1023 -- -- R/W 423 LAO
{64} PI I TIME 9999 SEC 0.3051543 0.01 32767 -- -- R/W 424 LAO
Point
Number
Descriptor
Factory
Default
(SI Units)
SI Units Slope
(SI Units)
Intercept
(SI Units)
Range On Text Off Text
Read/
Write
Param.
number
Network
Port
Type
Note 1

Danfoss VLT 6000 Specifications

General

Category	Controller
Cooling method	Forced air cooling
Enclosure	IP20
Output frequency range	0-500Hz
Protection features	Overvoltage, Undervoltage, Short circuit
Communication options	Profibus
Ambient temperature range	-10°C to +40°C
