Table 1 Quick Menu Items Description
During programming of parameters, mo-
tor may start. Be certain no one is in area
of motor or driven equipment when
changing parameters.
To Enter or Change Quick Menu Parameter
Data
Enter or change parameter data or settings in
accordance with the following procedure.
1. Press Quick Menu key.
2. Use ‘+’ and ‘-’ keys to find parameter you
chose to edit.
3. Press Change Data key.
4. Use ‘+’ and ‘-’ keys to select correct
parameter setting. To move to a different digit
within parameter, use t and u arrows.
Flashing underline indicates digit selected to
change.
5. Press Cancel key to disregard change, or
press OK key to accept change and enter
new setting.
6. Press Display key to return to normal display.
Example of Changing Parameter Data
Assume parameter 206, Ramp Up Time, is set at 60
seconds. Change the ramp up time to 100 seconds
in accordance with the following procedure.
1. Press Quick Menu key.
2. Press “+” key until you reach Parameter 206,
Ramp Up Time.
3. Press Change Data key.
4. Press t key twice – hundreds digit will flash.
5. Press “+” key once to change hundreds digit
to ‘1.’
6. Press u key once to move cursor to tens
digit.
Quick Menu
Item Number
Parameter Name Description
1 001 Language Selects language used for all displays.
2 102 Motor Power
Sets output characteristics of drive based on kW (HP) of
motor. See Table 2 to convert HP to kW.
3 103 Motor Voltage
Sets output characteristics of drive based on voltage of motor.
4
104 Motor
Frequency
Sets output characteristics of drive based on nominal
frequency of motor. This is typically equal to line frequency.
5 105 Motor Current
Sets output characteristics of drive based on full load curren
in amps (FLA) of motor. This sets overload protection for
motor.
6
106 Motor Nominal
Speed
Sets output characteristics of drive based on nominal full load
speed of motor.
7
201 Minimum
Frequency
Sets minimum controlled frequency at which motor will run.
8
202 Maximum
Frequency
Sets maximum controlled frequency at which motor will run.
9 206 Ramp Up Time
Sets time to accelerate motor from 0 Hz to nominal motor
frequency set in Quick Menu Item 4.
10
207 Ramp Down
Time
Sets time to decelerate motor from nominal motor frequency
set in Quick Menu Item 4 to 0 Hz.
11
323 Relay 1
Function
Sets function of high voltage Form C relay.
12
326 Relay 2
Function
Sets function of low voltage Form A relay.
To Next Page
