Point Database Definitions
TT
TT
T
able 9able 9
able 9able 9
able 9 Point Database Definitions
01 CTLR ADDRESS Predefined device address.
02 APPLICATION Predefined FLN application for use with VLT 6000 drive.
03 FREQ OUTPUT Displays drive speed in hertz.
06 CURRENT Displays drive output current in amps.
08 POWER Displays drive power output in kilowatts.
10 KWH Displays drive cumulative energy output in kilowatt-hours.
12 RUN TIME Displays number of hours drive has supplied power to motor.
13 DC BUS VOLT Displays drive voltage at DC bus in DC volts.
14 OUTPUT VOLT Displays output voltage to motor in AC volts.
15 MOTOR THERM Displays motor thermal load in percentage.
16 DRIVE THERM Displays drive thermal load in percentage.
17 CURR. SETUP Displays parameter setup number currently controlling drive.
18 TIMERS STAT Displays if temperature limit of motor, drive or motor thermistor has been exceeded.
19 CURRENT STAT Displays if drive is operating in current limit.
20 OVRD TIME Not used.
21 FWD.REV Displays direction of motor rotation, forward or reverse.
22 CMD FWD.REV Commands direction of motor rotation.
23 STOP.RUN Displays drive RUN/STOP status.
24 CMD STP.STRT Commands drive to start or stop.
25 FREEZE OUT Displays if output frequency is in freeze mode at present value.
26 CMD FREEZE Commands drive to freeze present output frequency.
27 COAST Displays if drive has been given a coast to stop command.
28 CMD COAST Commands drive to make motor coast to a stop.
29 DAY.NIGHT Selects day or night mode. (Has no effect on drive operation.)
30 CURRENT LIM Sets maximum drive output current to motor in amps.
31 ACCEL TIME 1 Sets motor ramp up time in seconds.
32 DECEL TIME 1 Sets motor ramp down time in seconds.
33 LOCK PANEL Used to lock out Hand Start, Off/Start, Auto Start and Reset keys on LCP.
34 SEL HAND.AUTO Displays operation in Hand or Auto control mode function.
35 RUN ENABLE Used to enable or disable drive operation in auto mode.
36 BUS TIME Sets time limit to determine loss of serial communication in seconds.
37 BUSTIME FUNC Selects drive response to loss of serial communication.
38 F OUT LOW Sets minimum drive output frequency.
39 F OUT HIGH Sets maximum drive output frequency.
40 RELAY OUT 1 Controls drive relay output 1. Note: Set relay output to corresponding function.
41 RELAY OUT 2 Controls drive relay output 2. Note: Set relay output to corresponding function.
42 PI STRT FR.S Displays status of point 61.
43 RELAY 1 STAT Displays status of FLN command to drive relay output 1.
44 RELAY 2 STAT Displays status of FLN command to drive relay output 2.
45 CURR. LIM.S Displays status of point 30.
46 F OUT LOW.S Displays status of point 38.
47 F OUT HIGH.S Displays status of point 39.
48 REF MIN.S Displays status of point 50.
49 REF MAX.S Displays status of point 51.
50 REF MIN Sets lowest frequency reference value for drive.
51 REF MAX Sets highest frequency reference value for drive.
52 REF STAT Displays if drive is running at commanded reference.
