Danfoss VLT 6000 User Manual

VLT
®
6000 HVAC
27
MG.60.G2.02 - VLT is a registered Danfoss Trademark
53 BUS REF Sends drive an external reference signal in percent.
54 SLEEP FREQ.S Displays status of point 57.
55 WAKEUP FREQ.S Displays status of point 58.
56 SLEEP TIME Displays run time at low speed before sleep mode starts.
57 SLEEP FREQ Sets output frequency required to activate sleep mode timer.
58 WAKEUP FREQ Sets command frequency required to restart motor after sleep mode.
59 SLEEP MODE Displays when drive is stopped in sleep mode.
60 INPUT REF Displays drive input reference in Hz or as selected in parameter 415.
61 PI STRT FREQ Sets drive frequency after start at which PID control is activated.
62 PI FEEDBACK Displays resulting feedback value in units selected in parameter 415.
63 PI GAIN Sets proportional gain of PID controller in percentage.
64 PI TIME Sets integral time of PID controller in seconds.
65 PI GAIN LIM Sets maximum gain for differentiator of PID controller.
66 LOWPASS FILTER Sets lowpass filter time constant for feedback circuit.
67 SLEEP BOOST Displays sleep boost set point in percentage.
68 FB FUNC Selects calculation method when two feedback signals are used.
69 SETPOINT 1 Sets setpoint for feedback 1 in units selected in parameter 415.
70 SETPOINT 2 Sets setpoint for feedback 2 in units selected in parameter 415.
71 FB MIN Sets minimum feedback signal value in units selected in parameter 415.
72 FB MAX Sets maximum feedback signal value in units selected in parameter 415.
73 BUS FB 1 Supplies feedback value for bus feedback 1 in percent.
74 BUS FB 2 Supplies feedback value for bus feedback 2 in percent.
75 AUTO RAMP Displays when drive deceleration rate is extended due to auto ramping.
76 VOLT STAT Displays if drive DC bus voltage exceeds high/low warning limits.
77 INVERT STAT Displays drive inverter status, ok or stall.
78 FREQ STAT Displays if drive is running outside of frequency limits of parameters 223 and 224.
79 CTRL STAT Displays whether drive is in local control or FLN serial bus.
80 DRV ENA STAT Displays if drive is enabled to start when run command given.
81 DRV RDY STAT Displays if drive control is ready or if a trip has occurred.
82 DRVCTRL STAT Displays drive control status as ready or not ready.
84 RESET Displays if a fault reset command has been given via serial bus.
85 START Displays if a run command has been given via serial bus.
86 Q.STOP Displays if a stop command has been given via serial bus.
87 TERM 53 Displays voltage value of signal on terminal 53 in volts.
88 TERM 54 Displays voltage value of signal on terminal 54 in volts.
89 TERM 60 Displays current value of signal on terminal 60 in mA.
90 OK.WARNING Displays if drive is in a warning condition.
91 LAST WARNING Displays last drive warning.
92 OK.FAULT Displays if drive has been tripped due to a fault.
93 LAST FAULT Displays last drive fault trip.
94 RESET FAULT Resets drive faults and resumes normal drive operation.
95 SETPOINT 1.S Displays status of point 69.
96 SETPOINT 2.S Displays status of point 70.
97 FB MIN.S Displays status of point 71.
98 FB MAX.S Displays status of point 72.
99 ERROR STATUS Not used.
Point Descriptor Definition
Number
