Danfoss VLT AHF 005 Service Guide

e30bc571.10
2
4
4
6
6
7
6
8
2
4
3
6
5
8
2
4
4
6
2
4
4
6
6
8
1 DC(+) plate stando
2 DC(+) plate screw
3 Midplate 1 stando
4 Midplate 1 screw
5 Midplate 2 stando
6 Midplate 2 screw
7 DC(-) plate stando
8 DC(-) plate screw
Illustration 11.21 Standard DC Cap Bank 12 Capacitor Layout
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 223
11 11
