1
3
2
4
130BF846.10
1 Contactor 3 A1/A2 contactor coil terminals
2 Disconnect 4 Contactor bracket
Illustration 11.40 Contactor and Disconnect
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 243
