Danfoss VLT AHF 005 Service Guide

130BF770.10
1
2
3
4
5
8
6
7
1 Nut (13 mm) 5 Input plate
2 AC input busbar 6 Mixing fan vent (cable not shown)
3 Nut (8 mm) 7 Cable retaining clip
4 Nuts (17 mm) and bolts for L1, L2, L3 connection 8 Nut (8 mm)
Illustration 13.8 Single Input Plate with Busbars only
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
276 Danfoss A/S © 02/2019 All rights reserved. MG94A502
