13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[70] SL Time-out 3 Use the result of timer 3 in the logic
rule.
[71] SL Time-out 4 Use the result of timer 4 in the logic
rule.
[72] SL Time-out 5 Use the result of timer 5 in the logic
rule.
[73] SL Time-out 6 Use the result of timer 6 in the logic
rule.
[74] SL Time-out 7 Use the result of timer 7 in the logic
rule.
[76] Digital Input x30
2
[77] Digital Input x30
3
[78] Digital Input x30
4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[100] Fire Mode
See 13-15 RS-FF Operand S, 13-16 RS-FF
Operand R.
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the rst logical operator to use on the
boolean inputs from parameter 13-40 Logic Rule
Boolean 1 and parameter 13-42 Logic Rule
Boolean 2.
Parameter numbers in square brackets stand
for the boolean inputs of parameters in group
13-** Smart Logic Control.
[0] DISABLED Ignores
•
Parameter 13-42 Logic Rule Boolean 2.
•
Parameter 13-43 Logic Rule Operator 2.
•
Parameter 13-44 Logic Rule Boolean 3.
[1] AND Evaluates the expression [13-40] AND [13-42].
[2] OR Evaluates the expression [13-40] OR [13-42].
[3] AND NOT Evaluates the expression [13-40] AND NOT
[13-42].
[4] OR NOT Evaluates the expression [13-40] OR NOT
[13-42].
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
[5] NOT AND Evaluates the expression NOT [13-40] AND
[13-42].
[6] NOT OR Evaluates the expression NOT [13-40] OR
[13-42].
[7] NOT AND
NOT
Evaluates the expression NOT [13-40] AND NOT
[13-42].
[8] NOT OR
NOT
Evaluates the expression NOT [13-40] OR NOT
[13-42].
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
Select the second boolean (TRUE or
FALSE) input for the selected logic
rule.
See parameter 13-40 Logic Rule
Boolean 1 for further descriptions of
options and their functions.
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
