Illustration 2.6 Indicator Lights
GLCP keys
Menu keys
The menu keys are divided into functions. The keys below
the display and indicator lights are used for parameter set-
up, including selection of display indication during normal
operation.
130BP045.10
Status
Quick
Menu
Main
Menu
Alarm
Log
Illustration 2.7 Menu Keys
[Status]
[Status] indicates the status of the frequency converter
and/or the motor. 3 dierent readouts can be selected by
pressing the [Status] key:
•
5-line readouts
•
4-line readouts
•
Smart logic control.
Press [Status] to select the display mode or for changing
back to Display mode from either Quick Menu mode, Main
Menu mode, or Alarm mode. Also press [Status] to toggle
between single or double readout mode.
[Quick Menu]
[Quick Menu] allows quick set-up of the frequency
converter. The most common HVAC functions can be
programmed here.
The Quick Menu consists of
•
My personal menu
•
Quick set-up
•
Function set-up
•
Changes made
•
Loggings
The
Function Set-up provides quick and easy access to all
parameters required for most HVAC applications including:
•
Most VAV and CAV supply and return fans.
•
Cooling tower fans.
•
Primary, secondary and condenser water pumps.
•
Other pump, fan and compressor applications.
Among other features, it also includes parameters for
selecting which variables to display in the LCP, digital
preset speeds, scaling of analog references, closed loop
single-zone and multi-zone applications, and specic
functions related to fans, pumps and compressors.
The Quick Menu parameters can be accessed immediately
unless a password has been created via
•
Parameter 0-60 Main Menu Password
•
Parameter 0-61 Access to Main Menu w/o Password
•
Parameter 0-65 Personal Menu Password
•
Parameter 0-66 Access to Personal Menu w/o
Password
It is possible to switch directly between Quick Menu mode
and Main Menu mode.
[Main Menu]
Press [Main Menu] to programme all parameters. The main
menu parameters can be accessed immediately unless a
password has been created via
•
Parameter 0-60 Main Menu Password
•
Parameter 0-61 Access to Main Menu w/o Password
•
Parameter 0-65 Personal Menu Password
•
Parameter 0-66 Access to Personal Menu w/o
Password
For most HVAC applications, it is not necessary to access
the main menu parameters. Instead, the Quick Menu, Quick
Set-up and Function Set-up provide the simplest and
quickest access to the most required parameters.
It is possible to switch directly between Main Menu mode
and Quick Menu mode.
Parameter shortcut can be carried out by pressing [Main
Menu] for 3 s. The parameter shortcut allows direct access
to any parameter.
[Alarm Log]
[Alarm Log] displays an alarm list of the 10 most recent
alarms (numbered A1-A10). To obtain more details about
an alarm, press the navigation keys to manoeuvre to the
alarm number and press [OK]. Information is displayed
about the condition of the frequency converter before it
enters the alarm mode.
The [Alarm Log] key on the LCP allows access to both
alarm log and maintenance log.
How to Programme
VLT
®
HVAC Drive FC 102
12 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
22
