Troubleshooting
•
Remove the power from the frequency converter
and check motor phase U.
ALARM 31, Motor phase V missing
Motor phase V between the frequency converter and the
motor is missing.
Troubleshooting
•
Remove the power from the frequency converter
and check motor phase V.
ALARM 32, Motor phase W missing
Motor phase W between the frequency converter and the
motor is missing.
Troubleshooting
•
Remove the power from the frequency converter
and check motor phase W.
ALARM 33, Inrush fault
Too many power-ups have occurred within a short time
period.
Troubleshooting
•
Let the unit cool to operating temperature.
WARNING/ALARM 34, Fieldbus communication fault
The eldbus on the communication option card is not
working.
WARNING/ALARM 36, Mains failure
This warning/alarm is only active if the supply voltage to
the frequency converter is lost and parameter 14-10 Mains
Failure is not set to option [0] No Function. Check the fuses
to the frequency converter and mains supply to the unit.
ALARM 38, Internal fault
When an internal fault occurs, a code number
dened in
Table 4.10 is displayed.
Troubleshooting
•
Cycle power.
•
Check that the option is properly installed.
•
Check for loose or missing wiring.
It may be necessary to contact the Danfoss supplier or
service department. Note the code number for further
troubleshooting directions.
Number Text
0 Serial port cannot be initialised. Contact the
Danfoss supplier or Danfoss Service Department.
256-258 Power EEPROM data is defective or too old.
Replace power card.
512-519 Internal fault. Contact the Danfoss supplier or
Danfoss Service Department.
783 Parameter value outside of minimum/maximum
limits.
1024-1284 Internal fault. Contact the Danfoss supplier or the
Danfoss Service Department.
1299 The option SW in slot A is too old.
1300 The option SW in slot B is too old.
Number Text
1302 The option SW in slot C1 is too old.
1315 The option SW in slot A is not supported (not
allowed).
1316 The option SW in slot B is not supported (not
allowed).
1318 The option SW in slot C1 is not supported (not
allowed).
1379-2819 Internal fault. Contact the Danfoss supplier or
Danfoss Service Department.
1792 HW reset of DSP.
1793 Motor derived parameters not transferred correctly
to DSP.
1794 Power data not transferred correctly at power-up
to DSP.
1795 The DSP has received too many unknown SPI
telegrams.
The frequency converter also uses this fault code if
the MCO does not power up correctly, for example
due to poor EMC protection or improper
grounding.
1796 RAM copy error.
2561 Replace control card.
2820 LCP stack overow.
2821 Serial port overow.
2822 USB port overow.
3072-5122 Parameter value is outside its limits.
5123 Option in slot A: Hardware incompatible with
control board hardware.
5124 Option in slot B: Hardware incompatible with
control board hardware.
5125 Option in slot C0: Hardware incompatible with
control board hardware.
5126 Option in slot C1: Hardware incompatible with
control board hardware.
5376-6231 Internal fault. Contact the Danfoss supplier or
Danfoss Service Department.
Table 4.10 Internal Fault Codes
ALARM 39, Heat sink sensor
No feedback from the heat sink temperature sensor.
The signal from the IGBT thermal sensor is not available on
the power card. The problem could be on the power card,
on the gatedrive card, or the ribbon cable between the
power card and gatedrive card.
WARNING 40, Overload of digital output terminal 27
Check the load connected to terminal 27 or remove the
short circuit connection. Check parameter 5-00 Digital I/O
Mode and 5-01 Terminal 27 Mode.
WARNING 41, Overload of digital output terminal 29
Check the load connected to terminal 29 or remove the
short circuit connection. Check parameter 5-00 Digital I/O
Mode and parameter 5-02 Terminal 29 Mode.
Troubleshooting
Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 219
4 4
