Danfoss VLT AQUA FC 202 User Manual

6-24 Terminal 54 Low Ref./Feedb. Value
Range: Function:
0 * [-999999.999 -
999999.999 ]
Enter the analog input scaling value that
corresponds to the low voltage/low
current value set in
parameter 6-20 Terminal 54 Low Voltage
and 6-22 Terminal 54 Low Current.
6-25 Terminal 54 High Ref./Feedb. Value
Range: Function:
100 * [-999999.999 -
999999.999 ]
Enter the analog input scaling value
that corresponds to the high voltage/
high current value set in
parameter 6-21 Terminal 54 High
Voltage and 6-23 Terminal 54 High
Current.
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as
an analog current output. A motor
current of 20 mA corresponds to I
max
.
[0] No operation
[100] Output freq. 0-100 0-100 Hz, (0-20 mA)
[101] Reference Min-Max Minimum reference - Maximum
reference, (0-20 mA)
[102] Feedback +-200%
-200% to +200% of 20-14 Maximum
Reference/Feedb., (0-20 mA)
[103] Motor cur. 0-Imax
0 - Inverter Max. Current (16-37 Inv.
Max. Current), (0-20 mA)
[104] Torque 0-Tlim
0 - Torque limit (4-16 Torque Limit
Motor Mode), (0-20 mA)
[105] Torque 0-Tnom 0 - Motor rated torque, (0-20 mA)
[106] Power 0-Pnom 0 - Motor rated power, (0-20 mA)
[107] Speed 0-HighLim 0 - Speed High Limit
(parameter 4-13 Motor Speed High
Limit [RPM] and 4-14 Motor Speed
High Limit [Hz]), (0-20 mA)
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed Loop 1 0-100%, (0-20 mA)
[114] Ext. Closed Loop 2 0-100%, (0-20 mA)
[115] Ext. Closed Loop 3 0-100%, (0-20 mA)
[116] Cascade Reference
[130] Out frq 0-100
4-20mA
0-100 Hz
[131] Reference 4-20mA Minimum Reference - Maximum
Reference
[132] Feedback 4-20mA
-200% to +200% of 20-14 Maximum
Reference/Feedb.
6-50 Terminal 42 Output
Option: Function:
[133] Motor cur. 4-20mA
0 - Inverter Max. Current (16-37 Inv.
Max. Current)
[134] Torq.0-lim 4-20 mA
0 - Torque limit (4-16 Torque Limit
Motor Mode)
[135] Torq.0-nom 4-20mA 0 - Motor rated torque
[136] Power 4-20mA 0 - Motor rated power
[137] Speed 4-20mA 0 - Speed High Limit (4-13 and 4-14)
[138] Torque 4-20mA
[139] Bus ctrl. 0-100%, (0-20 mA)
[140] Bus ctrl. 4-20 mA 0-100%
[141] Bus ctrl t.o. 0-100%, (0-20 mA)
[142] Bus ctrl t.o. 4-20mA 0-100%
[143] Ext. CL 1 4-20mA 0-100%
[144] Ext. CL 2 4-20mA 0-100%
[145] Ext. CL 3 4-20mA 0-100%
[146] Cascade Ref.
4-20mA
[147] Main act val
0-20mA
[148] Main act val
4-20mA
[150] Out frq 0-Fmax
4-20mA
[254] DC Link 0-20mA
[255] DC Link 4-20mA
NOTICE
Values for setting the Minimum Reference is found in
open loop parameter 3-02 Minimum Reference and for
closed loop 20-13 Minimum Reference/Feedb. - values for
maximum reference for open loop is found in
3-03 Maximum Reference and for closed loop
20-14 Maximum Reference/Feedb.
6-51 Terminal 42 Output Min Scale
Range: Function:
0 %* [0 - 200
%]
Scale for the minimum output (0 or 4 mA) of
the analog signal at terminal 42.
Set the value to be the percentage of the full
range of the variable selected in
parameter 6-50 Terminal 42 Output.
How to programme the freque... VLT AQUA Drive FC 202 Operation Instructions
100 MG20P402 - Rev. 2013-12-16
