Parameter number and name Unit
0-01 Language
Parameter 1-20 Motor Power [kW] kW
Parameter 1-22 Motor Voltage V
Parameter 1-23 Motor Frequency Hz
Parameter 1-24 Motor Current A
Parameter 1-25 Motor Nominal Speed RPM
Parameter 3-41 Ramp 1 Ramp Up Time s
Parameter 3-42 Ramp 1 Ramp Down Time s
Parameter 4-11 Motor Speed Low Limit [RPM] RPM
Parameter 4-13 Motor Speed High Limit [RPM] RPM
Parameter 1-29 Automatic Motor Adaptation (AMA)
Table 5.4 Q2 Quick Setup
5.1.4
Q3 Function Set-ups
The Function Set-up provides quick and easy access to all
parameters required for the majority of water and
wastewater applications including variable torque, constant
torque, pumps, dosing pumps, well pumps, booster
pumps, mixer pumps, aeration blowers and other pump
and fan applications. Amongst other features, it also
includes parameters for selecting which variables to display
on the LCP, digital preset speeds, scaling of analog
references, closed loop single zone and multi-zone
applications and specific functions related to water and
wastewater applications.
How to access Function Set-up - example:
1. Turn on the frequency converter (On LED lights)
28.8%
14.4Hz
Auto Remote Running
5.66A
2.63kW
0kWh
1 (1)
130BT110.11
Status
Illustration 5.2
2. Press the [Quick Menus] key (Quick Menus
choices appear).
130BT111.10
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
13.7% 13.0A 1(1)
Quick Menus
Illustration 5.3
3.
Press [
▲
]/[
▼
] navigation keys to scroll down to
Function Set-ups. Press [OK].
130BT112.10
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
69.3% 5.20A 1(1)
Quick Menus
Illustration 5.4
4.
Function Set-ups choices appear. Select Q3-1
General Settings. Press [OK].
130BA500.10
1190 RPM
Q3 - 1 General Settings
Q3 - 2 Open Loop Settings
Q3 - 3 Closed Loop Settings
0.000 1 (1)
Q3
Function Setups
Illustration 5.5
5.
Press [
▲
]/[
▼
] keys to scroll down to i.e. Q3-12
Analog Outputs. Press [OK].
130BA501.10
0.000 rpm
Q3 - 10 Clock Settings
Q3 - 11 Display Settings
Q3 - 12 Analog Output
Q3 - 13 Relays
0.000 1 (1)
Q3-1
General Settings
Illustration 5.6
6.
Select parameter 6-50 Terminal 42 Output. Press
[OK].
130BA502.10
0.000 rpm
6 - 50 Terminal 42 Output
(100) Output frequency
0.000 1 (1)
Q3-12
Analog Output
Illustration 5.7
7.
Press [
▲
]/[
▼
] keys to select between the different
choices. Press [OK].
130BA503.10
0.000 rpm
6 - 50 Terminal 42 Output
(107) Speed
0.000 1 (1)
Q3-12
Analog Output
Illustration 5.8
How to programme the freque... VLT AQUA Drive FC 202 Operation Instructions
MG20P402 - Rev. 2013-12-16 81
5 5
To Next Page
