Danfoss VLT AutomationDrive FC 302 Operating Instructions

+DC 89
FASTENER TORQUE: M10 19Nm (14 FT -LB)
+DC 89
130BA860.10
1
5
4
3
2
8
10
9
FUSE
C J3
ONNECT
CH22 CH22 CH22
CTI25MB
FASTENER TORQUE: M10 19Nm (14 FT -LB)
CTI25MB
CH22 CH22 CH22
7
6
1) 24 V DC, 5 A 5) Loadsharing
T1 Output Taps -DC +DC
Temp Switch 88 89
106 104 105 6) Control Transformer Fuses (2 or 4 pieces). See fuse tables for part numbers
2) Manual Motor Starters 7) SMPS Fuse. See fuse tables for part numbers
3) 30 A Fuse Protected Power Terminals 8) Manual Motor Controller fuses (3 or 6 pieces). See fuse tables for part numbers
4) Mains 9) Line Fuses, enclosure types F1 and F2 (3 pieces). See fuse tables for part
numbers
R S T 10) 30 Amp Fuse Protected Power fuses
L1 L2 L3
Illustration 3.59 Rectifier Cabinet, Enclosure Types F1, F2, F3 and F4
How to Install
VLT
®
Automation Drive FC 300 Operating Instructions
50 MG33U402 - Rev. 2013-12-16
33
