176FA259.10
Earth Terminals
:ASTENER TORQUE: MM8 9.6 Nm (7FT-LB)
ASTENER TORQUE: M10 19 Nm (14FT-LB)
S/L2 92
T/L3 93
R/L1 91
W/T3 98
Illustration 3.58 Position of Earth Terminals IP00, Enclosure Type E
How to Install
VLT
®
Automation Drive FC 300 Operating Instructions
MG33U402 - Rev. 2013-12-16 49
3 3
