9.3.2 Status Messages - Operating Mode
Table 95: Operating Mode
The drive requires external commands to execute functions. The start/stop commands are sent via the control
terminals and/or the serial communication.
The navigation keys on the LCP can be used to control the drive. Stop commands, reset, reversing, DC brake,
and other signals applied to the control terminals override local control.
The drive does not react to any control signal until [Auto On] or [Hand On] is pressed.
9.3.3 Status Messages - Reference Site
Table 96: Reference Site
The speed reference is given from:
External signals.
Serial communication.
Internal preset references.
The drive uses reference values from the LCP.
9.3.4 Status Messages - Operation Status
Table 97: Operation Status
AC brake was selected in parameter 2-10 Brake Function. The AC brake overmagnetizes the motor to achieve a
controlled slow down.
Automatic motor adaptation (AMA) was carried out successfully.
AMA is ready to start. To start, press [Hand On].
AMA process is in progress.
The brake chopper is in operation. The brake resistor absorbs the generative energy.
[2] Coast inverse was selected as a function for a digital input (parameter group 5–1* Digital Inputs). The corre-
sponding terminal is not connected.
Coast activated by serial communication.
No output from the drive to the motor.
[1] Ctrl. ramp-down was selected in parameter 14-10 Mains Failure.
The mains voltage is below the value set in parameter 14-11 Mains Voltage at Mains Fault.
The drive ramps down the motor in a controlled manner.
The drive output current is above the limit set in parameter 4-51 Warning Current High.
AQ262139143212en-000301 / 130R0879138 | Danfoss A/S © 2021.10
Maintenance, Diagnostics, and
Troubleshooting
VLT® AutomationDrive FC 302
Operating Guide
