Danfoss VLT CDS 302 User Manual

0-30 Unit for User-dened Readout
Option: Function:
[126] ft³/min
[127] ft³/h
[130] lbs / sec.
[131] lbs / min.
[132] lbs / hr.
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in. wtr. gage
[173] ft WG
[180] HP
0-31 Min Value of User-dened Readout
Range: Function:
0 CustomRea-
doutUnit*
[ -999999.99 -
par. 0-32
CustomRea-
doutUnit]
This parameter sets the min.
value of the custom dened
readout (occurs at zero speed).
Only possible to set dierent
from 0 is when selecting a
linear unit in
parameter 0-30 Unit for User-
dened Readout. For Quadratic
and Cubic units the minimum
value will be 0.
0-32 Custom Readout Max Value
Range: Function:
100 Custom-
ReadoutUnit*
[ par. 0-31 -
999999.99
CustomRea-
doutUnit]
This parameter sets the max
value to be shown when the
speed of the motor has reached
the set value for
parameter 4-13 Motor Speed High
Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed
Unit).
6.2.3 0-4* LCP Keypad
Enable and disable individual keys on the LCP keypad.
0-40 [Hand on] Key on LCP
Option: Function:
If parameter 0-40 [Hand on] Key on LCP is included
in the Quick Menu, then dene the password in
parameter 0-65 Quick Menu Password.
0-40 [Hand on] Key on LCP
Option: Function:
[0] Disabled Prevents accidental start of the frequency
converter in Hand mode.
[1] Enabled Prevents unauthorised start in Hand mode.
[2] Password
0-41 [O] Key on LCP
Option: Function:
Options are the same as in parameter 0-40 [Hand on]
Key on LCP.
0-42 [Auto on] Key on LCP
Option: Function:
Options are the same as in parameter 0-40 [Hand on]
Key on LCP.
0-43 [Reset] Key on LCP
Option: Function:
Options are the same as in parameter 0-40 [Hand on]
Key on LCP.
6.2.4 0-5* Copy/Save
Copy parameter settings between set-ups and to/from the
LCP.
0-50 LCP Copy
Option: Function:
[0] * No copy
[1] All to LCP Copies all parameters in all set-ups from
the frequency converter memory to the
LCP memory.
[2] All from LCP Copies all parameters in all set-ups from
the LCP memory to the frequency
converter memory.
[3] Size indep.
from LCP
Copies only the parameters that are
independent of the motor size.
0-51 Set-up Copy
Option: Function:
[0] No copy
[1] Copy to set-up 1 Copies all parameters in the present edit
set-up (dened in par. 0-11 Edit Set-up) to
Set-up 1. Likewise, select the option
corresponding to the other set-up(s).
[2] Copy to set-up 2
[3] Copy to set-up 3
[4] Copy to set-up 4
[9] Copy to all Copies the parameters in the present set-
up over to each of the set-ups 1 to 4.
