Parameter Setting Notes
Parameter 13-00 SL Controller
Mode
On
Parameter 13-01 Start Event TRUE
Parameter 13-02 Stop Event FALSE
Parameter 13-40 Logic Rule
Boolean 1 [0]
[37] Digital
Input DI32
Parameter 13-42 Logic Rule
Boolean 2 [0]
[2] Running
Parameter 13-41 Logic Rule
Operator 1 [0]
[3] AND
NOT
Parameter 13-40 Logic Rule
Boolean 1 [1]
[37] Digital
Input DI32
Parameter 13-42 Logic Rule
Boolean 2 [1]
[2] Running
Parameter 13-41 Logic Rule
Operator 1 [1]
[1] AND
Parameter 13-15 RS-FF
Operand S [0]
[26]
Logicrule 0
Output from 13-41
[0]
Parameter 13-16 RS-FF
Operand R [0]
[27]
Logicrule 1
Output from 13-41
[1]
Parameter 13-51 SL Controller
Event [0]
[94] RS
Flipop 0
Output from
evaluating 13-15
and 13-16
Parameter 13-52 SL Controller
Action [0]
[22] Run
Parameter 13-51 SL Controller
Event [1]
[27]
Logicrule 1
Parameter 13-52 SL Controller
Action [1]
[24] Stop
Table 6.9 Operators
13-15 RS-FF Operand S
Option: Function:
[0] FALSE
[1] TRUE
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
13-15 RS-FF Operand S
Option: Function:
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reverse
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Timeout 0
[31] SL Timeout 1
[32] SL Timeout 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] OK key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Timeout 3
[71] SL Timeout 4
[72] SL Timeout 5
[73] SL Timeout 6
[74] SL Timeout 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
