The Start-up Wizard for open loop applications
Parameter Option Default Function
0-01 Language
[0] English
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
[0] English Select the language for the display.
0-06 GridType
[0] 200-240 V/50 Hz/IT-grid
[1] 200-240 V/50 Hz/Delta
[2] 200-240 V/50 Hz
[10] 380-440 V/50 Hz/IT-grid
[11] 380-440 V/50 Hz/Delta
[12] 380-440 V/50 Hz
[20] 440-480 V/50 Hz/IT-grid
[21] 440-480 V/50 Hz/Delta
[22] 440-480 V/50 Hz
[30] 525-600 V/50 Hz/IT-grid
[31] 525-600 V/50 Hz/Delta
[32] 525-600 V/50 Hz
[100] 200-240 V/60 Hz/IT-grid
[101] 200-240 V/60 Hz/Delta
[102] 200-240 V/60 Hz
[110] 380-440 V/60 Hz/IT-grid
[111] 380-440 V/60 Hz/Delta
[112] 380-440 V/60 Hz
[120] 440-480 V/60 Hz/IT-grid
[121] 440-480 V/60 Hz/Delta
[122] 440-480 V/60 Hz
[130] 525-600 V/60 Hz/IT-grid
[131] 525-600 V/60 Hz/Delta
[132] 525-600 V/60 Hz
Size related
Select operating mode for restart upon
reconnection of the frequency converter to
mains voltage after power down.
0-60 Main Menu Password
0-999 0 Define the password for access to the LCP.
1-13 Compressor Selection
[24] VZH028-R410A
[25] VZH035-R410A
[26] VZH044-R410A
Size related Select the used compressor.
3-03 Maximum Reference
0-200 Hz 200 Hz The maximum reference is the lowest
obtainable by summing all references.
3-15 Reference 1 Source
[0] No function
[1] Analog in 53
[2] Analog in 54
[7] Pulse input 29
[11] Local bus reference
[1] Analog in 53 Select the input to be used for the reference
signal.
3-41 Ramp 1 Ramp Up Time
0.05-3600.0 s 30.00 s
Ramp-up time from 0 to 1-25 Motor Nominal
Speed.
3-42 Ramp 1 Ramp Down Time
0.05-3600.0 s 30.00 s Ramp down time from rated motor speed to
0.
Quick Guide Quick Guide
