Danfoss VLT CDS 803 Programming Guide

5-40 Function Relay
Array (Relay 1 [0], Relay 2 [1])
Select options to dene the function of the relays.
The selection of each mechanical relay is realized in an array
parameter.
Option: Function:
[41] Below
reference, low
The reference is lower than the
limit set in parameter 4-54 Warning
Reference Low.
[42] Above ref,
high
The reference is higher than the
limit set in parameter 4-55 Warning
Reference High.
[44] Oil boost
active
[45] Bus Control The output is congured in
parameter 5-90 Digital & Relay Bus
Control.
[60] Comparator 0 See parameter group 13-1*
Comparators. If Comparator 0 is
evaluated as TRUE, the output goes
high. Otherwise, it is low.
[61] Comparator 1 See parameter group 13-1*
Comparators. If Comparator 2 is
evaluated as TRUE, the output goes
high. Otherwise, it is low.
[62] Comparator 2 See parameter group 13-1*
Comparators. If Comparator 2 is
evaluated as TRUE, the output goes
high. Otherwise, it is low.
[63] Comparator 3 See parameter group 13-1*
Comparators. If Comparator 3 is
evaluated as TRUE, the output goes
high. Otherwise, it is low.
[64] Comparator 4 See parameter group 13-1*
Comparators. If Comparator 4 is
evaluated as TRUE, the output goes
high. Otherwise, it is low.
[65] Comparator 5 See parameter group 13-1*
Comparators. If Comparator 5 is
evaluated as TRUE, the output goes
high. Otherwise, it is low.
[70] Logic rule 0 See parameter group 13-4* Logic
Rules. If Logic rule 0 is evaluated as
TRUE, the output goes high.
Otherwise, it is low.
[71] Logic rule 1 See parameter group 13-4* Logic
Rules. If Logic rule 1 is evaluated as
TRUE, the output goes high.
Otherwise, it is low.
[72] Logic rule 2 See parameter group 13-4* Logic
Rules. If Logic rule 2 is evaluated as
5-40 Function Relay
Array (Relay 1 [0], Relay 2 [1])
Select options to dene the function of the relays.
The selection of each mechanical relay is realized in an array
parameter.
Option: Function:
TRUE, the output goes high.
Otherwise, it is low.
[73] Logic rule 3 See parameter group 13-4* Logic
Rules. If Logic rule 3 is evaluated as
TRUE, the output goes high.
Otherwise, it is low.
[74] Logic rule 4 See parameter group 13-4* Logic
Rules. If Logic rule 4 is evaluated as
TRUE, the output goes high.
Otherwise, it is low.
[75] Logic rule 5 See parameter group 13-4* Logic
Rules. If Logic rule 5 is evaluated as
TRUE, the output goes high.
Otherwise, it is low.
[80] SL digital
output A
See parameter 13-52 SL Controller
Action. The input goes high
whenever the smart logic action
[38] Set dig. out. A high is executed.
The input goes low whenever the
smart logic [32] Action Set dig. out.
A low is executed.
[81] SL digital
output B
See parameter 13-52 SL Controller
Action. The input goes high
whenever the smart logic action
[39] Set dig. out. B high is executed.
The input goes low whenever the
smart logic [33] Action Set dig. out. B
low is executed.
[82] SL digital
output C
See parameter 13-52 SL Controller
Action. The input goes high
whenever the smart logic action
[40] Set dig. out. C high is executed.
The input goes low whenever the
smart logic [34] Action Set dig. out. C
low is executed.
[83] SL digital
output D
See parameter 13-52 SL Controller
Action. The input goes high
whenever the smart logic [41]
Action Set dig. out. D high is
executed. The input goes low
whenever the smart logic [35]
Action Set dig. out. D low is
executed.
[160] No alarm The output is high when no alarm
is present.
[161] Running
reverse
The output is high when the
frequency converter runs counter-
Parameters Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 33
3 3
