13-44 Logic Rule Boolean 3
Array [6]
Select the third boolean (TRUE or FALSE) input for the selected
logic rule.
See parameter 13-40 Logic Rule Boolean 1 for further descriptions
of options and their functions.
Option: Function:
[73] SL Time-out 6
[74] SL Time-out 7
3.9.6 13-5* States
13-51 SL Controller Event
Array [20]
Select the boolean input (TRUE or FALSE) to dene the smart
logic controller event.
See parameter 13-02 Stop Event for further descriptions of options
and their functions.
Option: Function:
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current
range
[8] Below I low
[9] Above I high
[16] Thermal
warning
[17] Mains out of
range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
13-51 SL Controller Event
Array [20]
Select the boolean input (TRUE or FALSE) to dene the smart
logic controller event.
See parameter 13-02 Stop Event for further descriptions of options
and their functions.
Option: Function:
[36] Digital input
DI29
[39] Start
command
[40] Drive stopped
[42] Auto Reset
Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
13-52 SL Controller Action
Array [20]
Select the action corresponding to the SLC event. Actions are
executed when the corresponding event (dened in
parameter 13-51 SL Controller Event) is evaluated as true. The
following actions are available for selection:
Option: Function:
[0] * Disabled
[1] No action
[2] Select set-up 1 Changes the active set-up
(parameter 0-10 Active Set-up) to 1.
[3] Select set-up 2 Changes the active set-up
(parameter 0-10 Active Set-up) to 2.
[10] Select preset
ref 0
Selects preset reference 0.
[11] Select preset
ref 1
Selects preset reference 1.
[12] Select preset
ref 2
Selects preset reference 2.
[13] Select preset
ref 3
Selects preset reference 3.
[14] Select preset
ref 4
Selects preset reference 4.
[15] Select preset
ref 5
Selects preset reference 5.
[16] Select preset
ref 6
Selects preset reference 6.
[17] Select preset
ref 7
Selects preset reference 7. If the
active preset reference is changed,
it merges with other preset
Parameters
VLT
®
Compressor Drive CDS 803
52 Danfoss A/S © 06/2019 All rights reserved. MG18P202
