Danfoss VLT CDS 803 Programming Guide

13-42 Logic Rule Boolean 2
Array [6]
Select the second boolean (TRUE or FALSE) input for the selected
logic rule.
See parameter 13-40 Logic Rule Boolean 1 for further descriptions
of options and their functions.
Option: Function:
[39] Start
command
[40] Drive stopped
[42] Auto Reset
Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
13-43 Logic Rule Operator 2
Array [6]
Select the 2
nd
logical operator to be used on the boolean input
calculated in parameter 13-40 Logic Rule Boolean 1,
parameter 13-41 Logic Rule Operator 1, parameter 13-42 Logic Rule
Boolean 2, and the boolean input coming from
parameter 13-42 Logic Rule Boolean 2.
[13–44] signies the boolean input of parameter 13-44 Logic Rule
Boolean 3.
[13-40/13-42] signies the boolean input calculated in
parameter 13-40 Logic Rule Boolean 1, parameter 13-41 Logic Rule
Operator 1, and parameter 13-42 Logic Rule Boolean 2. [0] Disabled
(factory setting): Select this option to ignore
parameter 13-44 Logic Rule Boolean 3.
Option: Function:
[0] * Disabled
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
13-44 Logic Rule Boolean 3
Array [6]
Select the third boolean (TRUE or FALSE) input for the selected
logic rule.
See parameter 13-40 Logic Rule Boolean 1 for further descriptions
of options and their functions.
Option: Function:
[0] * False
13-44 Logic Rule Boolean 3
Array [6]
Select the third boolean (TRUE or FALSE) input for the selected
logic rule.
See parameter 13-40 Logic Rule Boolean 1 for further descriptions
of options and their functions.
Option: Function:
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current
range
[8] Below I low
[9] Above I high
[16] Thermal
warning
[17] Mains out of
range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[39] Start
command
[40] Drive stopped
[42] Auto Reset
Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
Parameters Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 51
3 3
