Danfoss VLT CDS 803 Programming Guide

13-40 Logic Rule Boolean 1
Array [6]
Select the rst boolean (TRUE or FALSE) input for the selected
logic rule.
Option: Function:
[34] Digital input
DI19
Use the value of DI19 in the logic
rule (High=TRUE).
[35] Digital input
DI27
Use the value of DI27 in the logic
rule (High=TRUE).
[36] Digital input
DI29
Use the value of DI29 in the logic
rule (High=TRUE).
[39] Start
command
This logic rule is TRUE if the
frequency converter is started by
any means (either via digital input,
or other).
[40] Drive stopped This logic rule is TRUE if the
frequency converter is stopped or
coasted by any means (either via
digital input, or other).
[42] Auto Reset
Trip
This logic rule is TRUE if the
frequency converter is tripped (but
not trip lock) and an automatic
reset is issued.
[50] Comparator 4 Use the result of comparator 4 in
the logic rule.
[51] Comparator 5 Use the result of comparator 5 in
the logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the
logic rule.
[70] SL Time-out 3 Use the result of timer 3 in the
logic rule.
[71] SL Time-out 4 Use the result of timer 4 in the
logic rule.
[72] SL Time-out 5 Use the result of timer 5 in the
logic rule.
[73] SL Time-out 6 Use the result of timer 6 in the
logic rule.
[74] SL Time-out 7 Use the result of timer 7 in the
logic rule.
13-41 Logic Rule Operator 1
Select the rst logical operator to use on the Boolean inputs
from parameter and parameter .
Option: Function:
[0] * Disabled
[1] AND
[2] OR
[3] AND NOT
13-41 Logic Rule Operator 1
Select the rst logical operator to use on the Boolean inputs
from parameter and parameter .
Option: Function:
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
13-42 Logic Rule Boolean 2
Array [6]
Select the second boolean (TRUE or FALSE) input for the selected
logic rule.
See parameter 13-40 Logic Rule Boolean 1 for further descriptions
of options and their functions.
Option: Function:
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current
range
[8] Below I low
[9] Above I high
[16] Thermal
warning
[17] Mains out of
range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
Parameters
VLT
®
Compressor Drive CDS 803
50 Danfoss A/S © 06/2019 All rights reserved. MG18P202
33
