13-52 SL Controller Action
Array [20]
Select the action corresponding to the SLC event. Actions are
executed when the corresponding event (dened in
parameter 13-51 SL Controller Event) is evaluated as true. The
following actions are available for selection:
Option: Function:
reference commands coming from
either the digital inputs or via a
eldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[22] Run Issues a start command to the
frequency converter.
[23] Run reverse Issues a start reverse command to
the frequency converter.
[24] Stop Issues a stop command to the
frequency converter.
[25] Qstop Issues a quick stop command to
the frequency converter.
[26] DC Brake Issues a DC stop command to the
frequency converter.
[27] Coast The frequency converter coasts
immediately. All stop commands
including the coast command stop
the SLC.
[28] Freeze output Freezes the output frequency of the
frequency converter.
[29] Start timer 0 Starts timer 0, see
parameter 13-20 SL Controller Timer
for further description.
[30] Start timer 1 Starts timer 1, see
parameter 13-20 SL Controller Timer
for further description.
[31] Start timer 2 Starts timer 2, see
parameter 13-20 SL Controller Timer
for further description.
[32] Set digital out
A low
Any output with digital output 1
selected is low (o).
[33] Set digital out
B low
Any output with digital output 2
selected is low (o).
[34] Set digital out
C low
Any output with digital output 3
selected is low (o).
[35] Set digital out
D low
Any output with digital output 4
selected is low (o).
[38] Set digital out
A high
Any output with digital output 1
selected is high (closed).
[39] Set digital out
B high
Any output with digital output 2
selected is high (closed).
13-52 SL Controller Action
Array [20]
Select the action corresponding to the SLC event. Actions are
executed when the corresponding event (dened in
parameter 13-51 SL Controller Event) is evaluated as true. The
following actions are available for selection:
Option: Function:
[40] Set digital out
C high
Any output with digital output 3
selected is high (closed).
[41] Set digital out
D high
Any output with digital output 4
selected is high (closed).
[60] Reset Counter
A
Resets counter A to zero.
[61] Reset Counter
B
Resets counter B to zero.
[70] Start Timer 3 Starts timer 3, see
parameter 13-20 SL Controller Timer
for further description.
[71] Start Timer 4 Starts timer 4, see
parameter 13-20 SL Controller Timer
for further description.
[72] Start Timer 5 Starts timer 5, see
parameter 13-20 SL Controller Timer
for further description.
[73] Start Timer 6 Starts timer 6, see
parameter 13-20 SL Controller Timer
for further description.
[74] Start Timer 7 Starts timer 7, see
parameter 13-20 SL Controller Timer
for further description.
[100] ResetAlarm
