6-72 Terminal 45 Digital Output
Select the function of terminal 45 as a digital current output. See
also parameter 6-70 Terminal 45 Mode. See
parameter 5-40 Function Relay for description of the options.
Option: Function:
[3] Drive ready/
remote control
[4] Standby / no
warning
[5] Drive running
[6] Running / no
warning
[7] Run in
range/no
warning
[8] Run on ref/no
warning
[9] Alarm
[10] Alarm or
warning
[12] Out of current
range
[13] Below current,
low
[14] Above current,
high
[16] Below speed,
low
[17] Above speed,
high
[19] Below
feedback, low
[20] Above
feedback, high
[21] Thermal
warning
[22] Ready, no
thermal
warning
[23] Remote, ready,
no thermal
warning
[24] Ready, Voltage
OK
[25] Reverse
[26] Bus OK
[35] External
Interlock
[36] Control word
bit 11
[37] Control word
bit 12
[41] Below
reference, low
6-72 Terminal 45 Digital Output
Select the function of terminal 45 as a digital current output. See
also parameter 6-70 Terminal 45 Mode. See
parameter 5-40 Function Relay for description of the options.
Option: Function:
[42] Above ref,
high
[44] Oil boost
active
[45] Bus Control
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital
output A
[81] SL digital
output B
[82] SL digital
output C
[83] SL digital
output D
[160] No alarm
[161] Running
reverse
[165] Local ref.
active
[166] Remote ref.
active
[167] Start
command
activ
[168] Drive in hand
mode
[169] Drive in auto
mode
6-73 Terminal 45 Output Min Scale
Range: Function:
0 %* [0 - 200 %] Scale for the minimum output (0
mA or 4 mA) of the analog signal
at terminal 45. Set the value to be
the percentage of the full range of
the variable selected in
parameter 6-71 Terminal 45 Analog
Output.
Parameters
VLT
®
Compressor Drive CDS 803
38 Danfoss A/S © 06/2019 All rights reserved. MG18P202
