6-74 Terminal 45 Output Max Scale
Scale for the maximum output (20 mA) of the analog signal at
terminal 45.
Range: Function:
100 %* [0 - 200 %] Set the value to be the percentage
of the full range of the variable
selected in parameter 6-71 Terminal
45 Analog Output.
(mA)
0%
20
0/4
100%
Current
Analogue
output
Min Scale
par. 6-73
Variable
for
output
example:
Power
Analogue
Output
Max Scale
par. 6-74
Illustration 3.9 Output Maximum
Scale
6-76 Terminal 45 Output Bus Control
Range: Function:
0* [0 - 16384 ] Holds the level of analog output if
controlled by bus.
3.7.5 6-9* Analog/Digital Output 42
Parameters for conguring the limits for analog/digital
output terminal 42. Analog outputs are current outputs:
0/4–20 mA. Resolution on analog outputs is 12 bit. Analog
output terminals can also be set up as digital output.
6-90 Terminal 42 Mode
Set terminal 42 to act as analog output or as digital output.
Option: Function:
[0] * 0-20 mA
[1] 4-20 mA
[2] Digital Output
6-91 Terminal 42 Analog Output
Select the function of terminal 42 as an analog current output.
See also parameter 6-90 Terminal 42 Mode.
Option: Function:
[0] * No operation
[100] Output
frequency
0–100 Hz
[101] Reference Min
Ref.
–Max
Ref.
[102] Feedback Min
FB
–Max
FB
[103] Motor Current 0–I
max
[106] Power 0–P
nom
6-91 Terminal 42 Analog Output
Select the function of terminal 42 as an analog current output.
See also parameter 6-90 Terminal 42 Mode.
Option: Function:
[139] Bus Control 0–100%
[254] DC Link
Voltage
6-92 Terminal 42 Digital Output
Select the function of Terminal 42 as an analog current output.
See also parameter 6-90 Terminal 42 Mode. See
parameter 5-40 Function Relay for description of the choices.
Option: Function:
[0] * No operation
[1] Control Ready
[2] Drive ready
[3] Drive ready/
remote control
[4] Standby / no
warning
[5] Drive running
[6] Running / no
warning
[7] Run in
range/no
warning
[8] Run on ref/no
warning
[9] Alarm
[10] Alarm or
warning
[12] Out of current
range
[13] Below current,
low
[14] Above current,
high
[16] Below speed,
low
[17] Above speed,
high
[19] Below
feedback, low
[20] Above
feedback, high
[21] Thermal
warning
[22] Ready, no
thermal
warning
[23] Remote, ready,
no thermal
warning
[24] Ready, Voltage
OK
Parameters Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 39
