16-37 Inv. Max. Current
Range: Function:
0 A* [0 - 655.35
A]
View the inverter maximum current.
The data is used for calculation of
frequency converter protection and
so on.
16-38 SL Controller State
Range: Function:
0* [0 - 20 ] View the actual state of the smart
logic controller (SLC).
3.12.4 16-5* Ref. & Feedb.
16-50 External Reference
Range: Function:
0 %* [-200 -
200 %]
View the total reference, the sum of
digital, analog, preset, bus, and
freeze references.
16-52 Feedback[Unit]
Range: Function:
0
ProcessCtrl
Unit*
[-4999 - 4999
ProcessCtrlUnit
]
View the feedback resulting from
the selection of scaling in
parameter 3-02 Minimum Reference
and parameter 3-03 Maximum
Reference.
16-54 Feedback 1 [Unit]
Range: Function:
0
ProcessCtrl
Unit*
[-999999.999
- 999999.999
ProcessCtrlUnit
]
View the feedback resulting from
the selection of scaling in
parameter 3-02 Minimum Reference
and parameter 3-03 Maximum
Reference.
16-55 Feedback 2 [Unit]
Range: Function:
0
ProcessCtrl
Unit*
[-999999.999
- 999999.999
ProcessCtrlUnit
]
View value of feedback 2, see
parameter group 20-0* Feedback.
The value is limited by settings in
parameter 20-13 Minimum Reference/
Feedb. and
parameter 20-14 Maximum
Reference/Feedb. Units as set in
parameter 20-12 Reference/Feedback
Unit.
3.12.5 16-6* Inputs and Outputs
16-60 Digital Input
Range: Function:
0* [0 - 4095 ] View actual state of the digital
inputs 18, 19, 27, and 29.
Bit 0 Unused
Bit 1 Unused
Bit 2 Digital input terminal 29
Bit 3 Digital input terminal 27
Bit 4 Digital input terminal 19
Bit 5 Digital input terminal 18
Bit 6–15 Unused
Table 3.7 Bits Denition
16-61 Terminal 53 Setting
View the setting of input terminal 54.
Option: Function:
[0] * Current mode
[1] Voltage mode
16-62 Analog input 53
View actual input on analog input 53.
Range: Function:
1* [0 - 20 ]
16-63 Terminal 54 Setting
View the setting of input terminal 54 (current or voltage).
Option: Function:
[0] * Current mode
[1] Voltage mode
16-64 Analog input 54
Range: Function:
1* [0 - 20 ] View the actual value at input 54.
16-65 Analog output 42 [mA]
Range: Function:
0 mA* [0 - 20 mA] View the actual value at output 42
in mA. The value shown reects the
selection in parameter 6-90 Terminal
42 Mode and
parameter 6-91 Terminal 42 Analog
Output.
16-66 Digital Output
Range: Function:
0* [0 - 63 ] View the binary value of all digital
outputs.
Denition:
X: Not used
0: Low
Parameters Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 61
