16-66 Digital Output
Range: Function:
1: High
XX None used
X0 Terminal 42 not used,
terminal 45 low.
X1 Terminal 42 not used,
terminal 45 high.
0X Terminal 42 low,
terminal 45 not used.
0 Terminal 42 low,
terminal 45 low.
1 Terminal 42 low,
terminal 45 high.
1X Terminal 42 high,
terminal 45 not used.
10 Terminal 42 high,
terminal 45 low.
11 Terminal 42 high,
terminal 45 high.
Table 3.8 Binary Value of Digital
Outputs
16-67 Pulse input 29 [Hz]
Range: Function:
0* [0 - 130000 ] View the actual frequency rate on
terminal 29.
16-71 Relay output
Range: Function:
0* [0 - 31 ] View the setting of the relay.
Bit 0~2 Unused
Bit 3 Relay 02
Bit 4 Relay 01
Bit 5~15 Unused
Table 3.9 Bits Denition
16-72 Counter A
View the present value of counter A. Counters are useful as
comparator operands, see parameter 13-10 Comparator Operand.
Range: Function:
0* [-32768 -
32767 ]
The value can be reset or changed
either via digital inputs (parameter
group 5-1* Digital Inputs) or by
using an SLC action
(parameter 13-52 SL Controller
Action).
16-73 Counter B
View the present value of counter B. Counters are useful as
comparator operands (parameter 13-10 Comparator Operand).
Range: Function:
0* [-32768 -
32767 ]
The value can be reset or changed
either via digital inputs (parameter
group 5-1* Digital Inputs) or by
using an SLC action
(parameter 13-52 SL Controller
Action).
16-79 Analog output 45 [mA]
Range: Function:
0 mA* [0 - 20 mA] View the actual value at output 45
in mA. The value shown reects the
selection in parameter 6-70 Terminal
45 Mode and
parameter 6-71 Terminal 45 Analog
Output.
3.12.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control
words.
16-86 FC Port REF 1
Range: Function:
0* [-32768 -
32767 ]
View the last received reference
from the FC port.
3.12.7 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range: Function:
0* [0 -
0xFFFFFFFFUL
]
View the alarm word sent via the
serial communication port in hex
code.
16-91 Alarm Word 2
Range: Function:
0* [0 -
0xFFFFFFFFUL
]
View the alarm word 2 sent via the
serial communication port in hex
code.
16-92 Warning Word
Range: Function:
0* [0 -
0xFFFFFFFFUL
]
View the warning word sent via the
serial communication port in hex
code.
Parameters
VLT
®
Compressor Drive CDS 803
