Danfoss VLT FC 100 Service Manual

380–480 V AC
FC 102 N110 N132 N160 N200 N250 N315
FC 103 N110 N132 N160 N200 N250 N315
FC 202 N110 N132 N160 N200 N250 N315
380–500 V AC FC 302 N90k N110 N132 N160 N200 N250
Overcurrent Warning
[A
rms
]
327 392 481 583 731 888
Overcurrent Alarm
1
(1.5 s delay)
[A
rms
]
330 395 483 585 734 893
Ground Fault Alarm
[A
rms
]
27 32 39 47 59 72
Short Circuit Alarm [Apk] 593 711 868 1051 1318 1595
Heatsink Overtemperature
°F [°C]
230 [110] 230 [110] 230 [110] 230 [110] 230 [110] 230 [110]
Heatsink Undertemperature
Warning
°F [°C]
32 [0] 32 [0] 32 [0] 32 [0] 32 [0] 32 [0]
Control Card Overtemperature
°F [°C]
167 [75] 167 [75] 167 [75] 176 [80] 176 [80] 176 [80]
Line Phase Warning (30 s delay) DC Bus Ripple Vpkpk 80 80 80 80 80 80
Line Phase Alarm (60 s delay) DC Bus Ripple Vpkpk 80 80 80 80 80 80
1) Based on crest factor of 1.414
Table 1.17 Warning and Alarm Trip Points
525–690 V AC
FC 102 N75 N90 N110 N132 N160 N200 N250 N315 N400
FC 103 N75 N90 N110 N132 N160 N200 N250 N315 N400
FC 202 N75 N90 N110 N132 N160 N200 N250 N315 N400
FC 302 N55 N75 N90 N110 N132 N160 N200 N250 N315
Overcurrent Warning
[A
rms
]
141 167 209 253 300 372 468 561 666
Overcurrent Alarm
1
(1.5 s delay)
[A
rms
]
255 255 255 255 330 483 483 585 734
Ground Fault Alarm
[A
rms
]
11 14 17 21 24 30 38 45 54
Short Circuit Alarm [Apk] 459 459 459 459 593 870 869 1050 1319
Heatsink Overtemperature °F [°C]
230
[110]
230
[110]
230
[110]
230
[110]
230
[110]
230
[110]
230
[110]
230
[110]
230
[110]
Heatsink Undertem-
perature Warning °F [°C] 32 [0] 32 [0] 32 [0] 32 [0] 32 [0] 32 [0] 32 [0] 32 [0] 32 [0]
Control Card Overtem-
perature °F [°C] 167 [75] 167 [75] 167 [75] 167 [75] 167 [75] 167 [75] 176 [80] 176 [80] 176 [80]
Line Phase Warning
(30 s delay)
DC Bus Ripple
Vpkpk 80 80 80 80 80 80 80 80 80
Line Phase Alarm
(60 s delay)
DC Bus Ripple
Vpkpk 80 80 80 80 80 80 80 80 80
1) Based on crest factor of 1.414
Table 1.18 Warning and Alarm Trip Points
Introduction Service Manual
MG94A222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 19
