4
2
5
5
6
3
3
1
130BB700.10
Illustration 3.30 Options Cabinet, frame size F11 and F13
1)
Pilz Relay Terminal 4) Safety Relay Coil Fuse with Pilz Relay
2) RCD or IRM Terminal See fuse tables for part numbers
3) Mains/6 phase 5) Mains Fuses, (6 pieces)
R1 S1 T1 R2 S2 T2 See fuse tables for part numbers
91-1 92-1 93-1 91-2 92-2 93-2 6) 2 x 3-phase manual disconnect
L1-1 L2-1 L3-1 L1-2 L2-2 L3-2
How to Install
VLT
®
Automation Drive FC 300 12-Pulse
Operating Instructions High Power
MG34Q202 - VLT
®
is a registered Danfoss trademark 37
3
3
