Danfoss VLT FC 300 Design Guide

FC 302 - Mains: 525-690V (T7) - 10% Duty Cycle
FC 302 P
m (HO)
R
min
R
br, nom
R
rec
P
br avg
Order no. Period Cable cross
section
Max. brake
torque with
R
rec
*
T7 [kW]
[Ω] [Ω] [Ω]
[kW] 175Uxxxx [s] [mm2] [%]
P400 400 1.9 2.2 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 150 (150)
P500 500 1.5 1.7 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 123 (150)
P560 560 1.4 1.5 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 118 (150)
P630 630 1.2 1.4 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 98 (150)
P710 710 1.2 1.3 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 87 (140)
P800 800 1.2 1.3 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 77 (124)
P900 900 1.2 1.3 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 68 (110)
P1M1 1000 1.2 1.3 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 61 (99)
P1M2 1200 1.2 1.3 4.2 / 2 = 2.1 50 x 2 = 100 2 x 1064 300 2 x 120 51 (83)
5.2.6 Ordering Numbers: Brake Resistors 40%
FC 301 - Mains: 200-240V (T2) - 40% Duty Cycle
FC 301 P
m (HO)
R
min
R
br, nom
R
rec
P
br avg
Order
no.
Period Cable cross
section
2
*
Therm.
relay
Max. brake
torque with
R
rec
*
T2 [kW]
[Ω] [Ω] [Ω]
[kW] 175Uxxxx [s] [mm2] [A] [%]
PK25 0.25 368 408 425 0.43 1941 120 1.5 1 154 (160)
PK37 0.37 248 276 310 0.80 1942 120 1.5 1.6 142 (160)
PK55 0.55 166 185 210 1.35 1943 120 1.5 2.5 141 (160)
PK75 0.75 121 135 145 0.26 1920 120 1.5 1.3 149 (160)
P1K1 1.1 81 91.4 90 0.43 1921 120 1.5 2.2 160 (160)
P1K5 1.5 58.5 66.2 65 0.80 1922 120 1.5 3.5 160 (160)
P2K2 2.2 40.2 44.6 50 1.00 1923 120 1.5 4.5 143 (160)
P3K0 3 29.1 32.4 35 1.35 1924 120 1.5 6.2 148 (160)
P3K7 3.7 22.5 25.9 25 3.00 1925 120 1.5 11 160 (160)
FC 302 - Mains: 200-240V (T2) - 40% Duty Cycle
FC 302 P
m (HO)
R
min
R
br, nom
R
rec
P
br avg
Order
no.
Period Cable cross
section
2
*
Therm.
relay
Max. brake
torque with
R
rec
*
T2 [kW]
[Ω] [Ω] [Ω]
[kW] 175Uxxxx [s] [mm2] [A] [%]
PK25 0.25 382 467 425 0.43 1941 120 1.5 1.0 160 (160)
PK37 0.37 279 315 310 0.80 1942 120 1.5 1.6 160 (160)
PK55 0.55 189 211 210 1.35 1943 120 1.5 2.5 160 (160)
PK75 0.75 130 154 145 0.26 1920 120 1.5 1.3 160 (160)
P1K1 1.1 81 104 90 0.43 1921 120 1.5 2.2 160 (160)
P1K5 1.5 58.5 75.7 65 0.80 1922 120 1.5 3.5 160 (160)
P2K2 2.2 45 51 50 1.00 1923 120 1.5 4.5 160 (160)
P3K0 3 31.5 37 35 1.35 1924 120 1.5 6.2 160 (160)
P3K7 3.7 22.5 29.6 25 3.00 1925 120 1.5 11 160 (160)
