Danfoss VLT FC 300 Design Guide

FC 302 - Mains: 525-600V (T6) - 40% Duty Cycle
FC 302 P
m (HO)
R
min
R
br, nom
R
rec
P
br avg
Order
no.
Period Cable
cross
section
2
*
Therm.
relay
Max. brake
torque with
R
rec
*
T6 [kW]
[Ω] [Ω] [Ω]
[kW] 175Uxxxx [s] [mm2] [A] [%]
PK75 0.75 620 905 620 0.26 1940 120 1.5 0.6 160 (160)
P1K1 1.1 550 614 620 0.26 1940 120 1.5 0.6 160 (160)
P1K5 1.5 380 448 425 1 1941 120 1.5 1 160 (160)
P2K2 2.2 270 302 310 1.6 1942 120 1.5 1.6 160 (160)
P3K0 3 189 219 210 2.5 1943 120 1.5 2.5 160 (160)
P4K0 4 135 162 150 3.7 1944 120 1.5 3.7 160 (160)
P5K5 5.5 99 117 110 4.7 1945 120 1.5 4.7 160 (160)
P7K5 7.5 72 84.5 80 6.1 1946 120 1.5 6.1 160 (160)
P11K 11 40 57 40 11 1948 120 1.5 8.3 160 (160)
P15K 15 36 41.3 40 11 1948 120 1.5 11 160 (160)
P18K 18.5 27 33.2 30 18 1949 120 2.5 18 160 (160)
P22K 22 22.5 27.6 25 23 1950 120 4 23 150 (150)
P30K 30 18 21.6 20 25 1951 120 4 25 150 (150)
P37K 37 13.5 17.3 15 32 1952 120 10 32 150 (150)
P45K 45 10.8 14.2 12 40 1953 120 10 40 150 (150)
P55K 55 8.8 11.6 9.8 62 2007 120 16 62 150 (150)
P75K 75 6.6 8.4 7.3 72 0068 120 25 72 150 (150)
P90K 90 4.7 7 150 (150)
P110 110 4.7 5.8 150 (150)
P132 132 4.2 4.8 150 (150)
P160 160 3.4 4 150 (150)
P200 200 2.7 3.2 150 (150)
P250 250 2.2 2.5 146 (150)
P315 315 1.7 2 (150)
P355 355 1.6 1.8 (150)
P400 400 1.4 1.6 (150)
P450 450 1.2 1.3 (150)
P500 500 1.2 1.3 (150)
P560 560 1.2 1.3 (130)
P670 670 1.2 1.3 (116)
P750 750 1.2 1.3 (103)
P850 850 1.2 1.3 (91)
P1M0 1000 1.2 1.3 (73)
P1M1 1100 1.2 1.3
How to Order FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 109
5 5
