Mains Supply 3 x 380 - 500V AC (FC 302), 3 x 380 - 480V AC (FC 301)
FC 301/FC 302 P30K P37K P45K P55K P75K
High/ Normal Load
1)
HO NO HO NO HO NO HO NO HO NO
Typical Shaft output [kW] 30 37 37 45 45 55 55 75 75 90
Enclosure IP20 B4 C3 C3 C4 C4
Enclosure IP21 C1 C1 C1 C2 C2
Enclosure IP55, 66 C1 C1 C1 C2 C2
Output current
Continuous
(3 x 380-440V) [A]
61 73 73 90 90 106 106 147 147 177
Intermittent (60 sec.
overload)
(3 x 380-440V) [A]
91.5 80.3 110 99 135 117 159 162 221 195
Continuous
(3 x 441-500V) [A]
52 65 65 80 80 105 105 130 130 160
Intermittent (60 sec
overload)
(3 x 441-500V) [A]
78 71.5 97.5 88 120 116 158 143 195 176
Continuous kVA
(400V AC) [kVA]
42.3 50.6 50.6 62.4 62.4 73.4 73.4 102 102 123
Continuous kVA
(460V AC) [kVA]
51.8 63.7 83.7 104 128
Max. input current
Continuous
(3 x 380-440V) [A]
55 66 66 82 82 96 96 133 133 161
Intermittent (60 sec
overload)
(3 x 380-440V) [A]
82.5 72.6 99 90.2 123 106 144 146 200 177
Continuous
(3 x 441-500V) [A]
47 59 59 73 73 95 95 118 118 145
Intermittent (60 sec
overload)
(3 x 441-500V) [A]
70.5 64.9 88.5 80.3 110 105 143 130 177 160
Additional specifications
IP20 max. cable cross-
section
5)
(mains and
motor)
35 (2) 50 (1) 50 (1) 150 (300mcm) 150 (300mcm)
IP20 max. cable cross-
section
5)
(brake and load
sharing)
35 (2) 50 (1) 50 (1) 95 (4/0) 95 (4/0)
IP21, 55, 66 max. cable
cross-section
5)
(mains,
motor) [mm
2
(AWG)]
2)
50 (1) 50 (1) 50 (1) 150 (300MCM) 150 (300MCM)
IP21, 55, 66 max. cable
cross-section
5)
(brake, load
sharing) [mm
2
(AWG)]
2)
50 (1) 50 (1) 50 (1) 95 (3/0) 95 (3/0)
Max cable size with mains
disconnect [mm
2
(AWG)]
2)
50, 35, 35
(1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350MCM, 300MCM,
4/0)
Estimated power loss
at rated max. load [W]
4)
570 698 697 843 891 1083 1022 1384 1232 1474
Weight,
enclosure IP21, IP55, 66
[kg]
45 45 45 65 65
Efficiency
4)
0.98 0.98 0.98 0.98 0.99
For fuse ratings, see 8.3.1 Fuses
1) High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
2) American Wire Gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within +/-15% (tolerence relates to variety in voltage and
cable conditions).
Values are based on a typical motor efficiency (eff2/eff3 border line). Motors with lower efficiency will also add to the power loss in the
frequency converter and opposite.
If the switching frequency is increased compared to the default setting, the power losses may rise significantly.
LCP and typical control card power consumptions are included. Further options and customer load may add up to 30W to the losses.
(Though typical only 4W extra for a fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be allowed for (+/-5%).
5) The three values for the max. cable cross section are for single core, flexible wire and flexible wire with sleeve, respectively.
FC 300 Selection FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 65
