Danfoss VLT FC 300 Design Guide

Mains Supply 3 x 380 - 500VAC
FC 302 P450 P500 P560 P630 P710 P800
High/ Normal Load* HO NO HO NO HO NO HO NO HO NO HO NO
Typical Shaft output at
400V [kW]
450 500 500 560 560 630 630 710 710 800 800 1000
Typical Shaft output at
460V [HP]
600 650 650 750 750 900 900 1000 1000 1200 1200 1350
Typical Shaft output at
500V [kW]
530 560 560 630 630 710 710 800 800 1000 1000 1100
EnclosureIP21, 54 without/
with options cabinet
F1/ F3 F1/ F3 F1/ F3 F1/ F3 F2/ F4 F2/ F4
Output current
Continuous
(at 400V) [A]
800 880 880 990 990 1120 1120 1260 1260 1460 1460 1720
Intermittent (60 sec
overload)
(at 400V) [A]
1200 968 1320 1089 1485 1232 1680 1386 1890 1606 2190 1892
Continuous
(at 460/ 500V) [A]
730 780 780 890 890 1050 1050 1160 1160 1380 1380 1530
Intermittent (60 sec
overload)
(at 460/ 500V) [A]
1095 858 1170 979 1335 1155 1575 1276 1740 1518 2070 1683
Continuous kVA
(at 400V) [kVA]
554 610 610 686 686 776 776 873 873 1012 1012 1192
Continuous kVA
(at 460V) [kVA]
582 621 621 709 709 837 837 924 924 1100 1100 1219
Continuous kVA
(at 500V) [kVA]
632 675 675 771 771 909 909 1005 1005 1195 1195 1325
Max. input current
Continuous
(at 400V ) [A]
779 857 857 964 964 1090 1090 1227 1227 1422 1422 1675
Continuous (at 460/ 500V)
[A]
711 759 759 867 867 1022 1022 1129 1129 1344 1344 1490
Max. cable size,motor
[mm
2
(AWG
2)
)]
8x150
(8x300 mcm)
12x150
(12x300 mcm)
Max. cable size,mains F1/
F2 [mm
2
(AWG
2)
)]
8x240
(8x500 mcm)
Max. cable size,mains F3/
F4 [mm
2
(AWG
2)
)]
8x456
(8x900 mcm)
Max. cable size,
loadsharing [mm
2
(AWG
2)
)]
4x120
(4x250 mcm)
Max. cable size, brake
[mm
2
(AWG
2)
)
4x185
(4x350 mcm)
6x185
(6x350 mcm)
Max. external mains fuses
[A]
1
1600 2000 2500
Estimated power loss
at 400V [W]
4)
9031 10162 10146 11822 10649 12512 12490 14674 14244 17293 15466 19278
Estimated power loss
at 460V [W]
8212 8876 8860 10424 9414 11595 11581 13213 13005 16229 14556 16624
F3/F4 max. added losses
A1 RFI, CB or Disconnect,
& contactor F3/F4
893 963 951 1054 978 1093 1092 1230 2067 2280 2236 2541
Max. panel options losses 400
Weight,
enclosure IP21, IP 54 [kg]
1004/ 1299 1004/ 1299 1004/ 1299 1004/ 1299 1246/ 1541 1246/ 1541
Weight Rectifier Module
[kg]
102 102 102 102 136 136
Weight Inverter Module
[kg]
102 102 102 136 102 102
Efficiency
4)
0.98
Output frequency 0-600 Hz
Heatsink overtemp. trip 95 °C
Power card ambient trip 75 °C
* High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
