Danfoss VLT FC 300 Design Guide

Mains Supply 6 x 380 - 500V AC, 12-Pulse
FC 302 P450 P500 P560 P630 P710 P800
High/ Normal Load * HO NO HO NO HO NO HO NO HO NO HO NO
Typical Shaft output at 400V
[kW]
450 500 500 560 560 630 630 710 710 800 800 1000
Typical Shaft output at 460V
[HP]
600 650 650 750 750 900 900 1000 1000 1200 1200 1350
Typical Shaft output at 500V
[kW]
530 560 560 630 630 710 710 800 800 1000 1000 1100
EnclosureIP21, 54 without/
with options cabinet
F10/F11 F10/F11 F10/F11 F10/F11 F12/F13 F12/F13
Output current
Continuous
(at 400V) [A]
800 880 880 990 990 1120 1120 1260 1260 1460 1460 1720
Intermittent (60 sec overload)
(at 400V) [A]
1200 968 1320 1089 1485 1232 1680 1386 1890 1606 2190 1892
Continuous
(at 460/ 500V) [A]
730 780 780 890 890 1050 1050 1160 1160 1380 1380 1530
Intermittent (60 sec overload)
(at 460/ 500V) [A]
1095 858 1170 979 1335 1155 1575 1276 1740 1518 2070 1683
Continuous KVA
(at 400V) [KVA]
554 610 610 686 686 776 776 873 873 1012 1012 1192
Continuous KVA
(at 460V) [KVA]
582 621 621 709 709 837 837 924 924 1100 1100 1219
Continuous KVA
(at 500V) [KVA]
632 675 675 771 771 909 909 1005 1005 1195 1195 1325
Max. input current
Continuous
(at 400V) [A]
779 857 857 964 964 1090 1090 1227 1227 1422 1422 1675
Continuous (at 460/ 500V) [A] 711 759 759 867 867 1022 1022 1129 1129 1344 1344 1490
Max. cable size,motor [mm
2
(AWG
2)
)]
8x150
(8x300 mcm)
12x150
(12x300 mcm)
Max. cable size,mains [mm
2
(AWG
2)
)]
6x120
(6x250 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
4x185
(4x350 mcm)
6x185
(6x350 mcm)
Max. external mains fuses [A]
1
900 1500
Estimated power loss
at 400V [W]
4)
9492 10647 10631 12338 11263 13201 13172 15436 14967 18084 16392 20358
Estimated power loss
at 460V [W]
8730 9414 9398 11006 10063 12353 12332 14041 13819 17137 15577 17752
F9/F11/F13 max. added losses
A1 RFI, CB or Disconnect, &
contactor F9/F11/F13
893 963 951 1054 978 1093 1092 1230 2067 2280 2236 2541
Max. panel options losses 400
Weight,
enclosure IP21, IP 54 [kg]
1004/ 1299 1004/ 1299 1004/ 1299 1004/ 1299 1246/ 1541 1246/ 1541
Weight Rectifier Module [kg] 102 102 102 102 136 136
Weight Inverter Module [kg] 102 102 102 136 102 102
Efficiency
4)
0.98
Output frequency 0-600Hz
Heatsink overtemp. trip 95 °C
Power card ambient trip 75 °C
* High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
FC 300 Selection FC 300 Design Guide
70 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
44
