Danfoss VLT FC 300 Design Guide

Mains Supply 3 x 525 - 600V AC
FC 302 P11K P15K P18K P22K P30K
High/ Normal Load
1)
HO NO HO NO HO NO HO NO HO NO
Typical Shaft Output [kW] 11 15 15 18.5 18.5 22 22 30 30 37
Enclosure IP21, 55, 66 B1 B1 B2 B2 C1
Enclosure IP20 B3 B3 B4 B4 B4
Output current
Continuous
(3 x 525-550V ) [A]
19 23 23 28 28 36 36 43 43 54
Intermittent
(3 x 525-550V ) [A]
30 25 37 31 45 40 58 47 65 59
Continuous
(3 x 525-600V ) [A]
18 22 22 27 27 34 34 41 41 52
Intermittent
(3 x 525-600V ) [A]
29 24 35 30 43 37 54 45 62 57
Continuous kVA (550V AC)
[kVA]
18.1 21.9 21.9 26.7 26.7 34.3 34.3 41.0 41.0 51.4
Continuous kVA (575V AC)
[kVA]
17.9 21.9 21.9 26.9 26.9 33.9 33.9 40.8 40.8 51.8
Max. input current
Continuous
at 550V [A]
17.2 20.9 20.9 25.4 25.4 32.7 32.7 39 39 49
Intermittent
at 550V [A]
28 23 33 28 41 36 52 43 59 54
Continuous
at 575V [A]
16 20 20 24 24 31 31 37 37 47
Intermittent
at 575V [A]
26 22 32 27 39 34 50 41 56 52
Additional specifications
IP21, 55, 66 max. cable
cross-section
5)
(mains, brake,
load sharing) [mm
2
(AWG)]
2)
16, 10, 10 (6, 8, 8) 16, 10, 10 (6, 8, 8) 35,-,-(2,-,-) 35,-,-(2,-,-) 50,-,- (1,-,-)
IP21, 55, 66 max. cable
cross-section
5)
(motor) [mm
2
(AWG)]
2)
10, 10,- (8, 8,-) 10, 10,- (8, 8,-) 35, 25, 25 (2, 4, 4) 35, 25, 25 (2, 4, 4) 50,-,- (1,-,-)
IP20 max. cable cross-
section
5)
(mains, brake,
motor and load sharing)
10, 10,- (8, 8,-) 10, 10,- (8, 8,-) 35,-,-(2,-,-) 35,-,-(2,-,-) 35,-,-(2,-,-)
Max. cable cross-section
with Disconnect [mm
2
(AWG)]
2)
16, 10, 10
(6, 8, 8)
50, 35, 35
(1,2, 2)
Estimated power loss
at rated max. load [W]
4)
225 285 329 700 700
Weight,
enclosure IP21, [kg]
23 23 27 27 27
Weight,
enclosure IP20 [kg]
12 12 23.5 23.5 23.5
Efficiency
4)
0.98 0.98 0.98 0.98 0.98
FC 300 Selection FC 300 Design Guide
72 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
44
