Danfoss VLT Midi Drive FC 280

0 - 4294967295 *0
12-06 Name Servers
0 - 4294967295 *0
12-07 Domain Name
1 - 48 *0
12-08 Host Name
1 - 48 *0
12-09 Physical Address
0 - 17 *0
12-1* Ethernet Link Parameters 12-10 Link Status *[0] No Link [1] Link 12-11 Link Duration
0 - 0 *Size related
12-12 Auto Negotiation [0] O
*[1] On 12-13 Link Speed *[0] None [1] 10 Mbps [2] 100 Mbps 12-14 Link Duplex
[0] Half Duplex *[1] Full Duplex 12-18 Supervisor MAC
0 - 2147483647 *0
12-19 Supervisor IP Addr.
0 - 2147483647 *0
12-2* Process Data 12-20 Control Instance
0 - 255 *Size related
12-21 Process Data Cong Write
[0] None [302] Minimum Reference [303] Maximum Reference [312] Catch up/slow Down Value
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time [380] Jog Ramp Time [381] Quick Stop Ramp Time [412] Motor Speed Low Limit [Hz]
[414] Motor Speed High Limit [Hz]
[416] Torque Limit Motor Mode [417] Torque Limit Generator Mode [553] Term. 29 High Ref./Feedb. Value [558] Term. 33 High Ref./Feedb. Value [590] Digital & Relay Bus Control [593] Pulse Out 27 Bus Control
[615] Terminal 53 High Ref./Feedb. Value [625] Terminal 54 High Ref./Feedb. Value [696] Terminal 42 Output Bus Control
[748] PCD Feed Forward [890] Bus Jog 1 Speed [891] Bus Jog 2 Speed [1680] Fieldbus CTW 1 [1682] Fieldbus REF 1
[3401] PCD 1 Write For Application
[3402] PCD 2 Write For Application [3403] PCD 3 Write For Application
[3404] PCD 4 Write For Application
[3405] PCD 5 Write For Application [3406] PCD 6 Write For Application
[3407] PCD 7 Write For Application
[3408] PCD 8 Write For Application
[3409] PCD 9 Write For Application
[3410] PCD 10 Write For Application
12-22 Process Data Cong Read
[0] None [1500] Operating hours [1501] Running Hours [1502] kWh Counter
[1600] Control Word [1601] Reference [Unit] [1602] Reference [%]
[1603] Status Word [1605] Main Actual Value [%] [1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp] [1612] Motor Voltage [1613] Frequency [1614] Motor current [1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM] [1618] Motor Thermal [1620] Motor Angle [1622] Torque [%]
[1630] DC Link Voltage [1633] Brake Energy /2 min
[1634] Heatsink Temp. [1635] Inverter Thermal
[1638] SL Controller State
[1639] Control Card Temp.
[1650] External Reference
[1652] Feedback[Unit] [1653] Digi Pot Reference [1657] Feedback [RPM]
[1660] Digital Input [1661] Terminal 53 Setting [1662] Analog input 53
[1663] Terminal 54 Setting [1664] Analog input 54 [1665] Analog output 42 [mA]
[1666] Digital Output [1667] Pulse input 29 [Hz]
[1668] Pulse input 33 [Hz]
[1669] Pulse output 27 [Hz]
[1671] Relay output [1672] Counter A [1673] Counter B [1674] Prec. Stop Counter
[1684] Comm. Option STW
[1685] FC Port CTW 1 [1690] Alarm Word
[1691] Alarm Word 2 [1692] Warning Word
[1693] Warning Word 2 [1694] Ext. Status Word
[1695] Ext. Status Word 2
[1697] Alarm Word 3
[3421] PCD 1 Read For Application
[3422] PCD 2 Read For Application
[3423] PCD 3 Read For Application
[3424] PCD 4 Read For Application
[3425] PCD 5 Read For Application
[3426] PCD 6 Read For Application
[3427] PCD 7 Read For Application
[3428] PCD 8 Read For Application [3429] PCD 9 Read For Application
[3430] PCD 10 Read For Application
[3450] Actual Position [3456] Track Error 12-23 Process Data Cong Write Size
8 - 32 *16
12-24 Process Data Cong Read Size
8 - 32 *16
12-28 Store Data Values *[0] O
[2] Store all setups 12-29 Store Always *[0] O [1] On 12-3* EtherNet/IP 12-30 Warning Parameter
0 - 2147483647 *0
12-31 Net Reference *[0] O [1] On 12-32 Net Control *[0] O [1] On 12-33 CIP Revision
0 - 65535 *Size related
12-34 CIP Product Code
0 - 65535 *Size related
12-35 EDS Parameter
0 - 0 *0
12-37 COS Inhibit Timer
0 - 65535 *0
12-38 COS Filter
0 - 65535 *0
12-6* Ethernet PowerLink 12-60 Node ID
1 - 239 *1
12-62 SDO Timeout
0 - 2000000000 ms *30000 ms
12-63 Basic Ethernet Timeout
0 - 2000000.000 ms *5000.000 ms
12-66 Threshold
0 - 2000000000 *15
12-67 Threshold Counters
0 - 4294967295 *0
12-68 Cumulative Counters
0 - 2147483647 *0
12-69 Ethernet PowerLink Status
0 - 4294967295 *0
12-8* Other Ethernet Services 12-80 FTP Server *[0] Disabled [1] Enabled 12-81 HTTP Server *[0] Disabled [1] Enabled 12-82 SMTP Service *[0] Disabled [1] Enabled 12-83 SNMP Agent [0] Disabled *[1] Enabled
12-84 Address Conict Detection
[0] Disabled
*[1] Enabled 12-89 Transparent Socket Channel Port
0 - 65535 *4000
12-9* Advanced Ethernet Services 12-90 Cable Diagnostic *[0] Disabled [1] Enabled 12-91 Auto Cross Over
[0] Disabled *[1] Enabled 12-92 IGMP Snooping [0] Disabled *[1] Enabled 12-93 Cable Error Length
0 - 65535 *0
12-94 Broadcast Storm Protection
-1 - 20 % *-1 %
12-95 Inactivity timeout
0 - 3600 *120
12-96 Port Cong
[0] Normal [1] Mirror Port 1 to 2
[2] Mirror Port 2 to 1
[10] Port 1 disabled [11] Port 2 disabled [254] Mirror Int. Port to 1 [255] Mirror Int. Port to 2
12-97 QoS Priority
0 - 63 *Size related
12-98 Interface Counters
0 - 4294967295 *4000
12-99 Media Counters
0 - 4294967295 *0
13-** Smart Logic 13-0* SLC Settings 13-00 SL Controller Mode
*[0] O
[1] On 13-01 Start Event [0] False [1] True
[2] Running [3] In range [4] On reference [7] Out of current range
[8] Below I low [9] Above I high [16] Thermal warning [17] Mains out of range
[18] Reversing [19] Warning [20] Alarm (trip) [21] Alarm (trip lock)
[22] Comparator 0 [23] Comparator 1 [24] Comparator 2
[25] Comparator 3 [26] Logic rule 0 [27] Logic rule 1 [28] Logic rule 2 [29] Logic rule 3 [33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27 [36] Digital input DI29
*[39] Start command [40] Drive stopped
[42] Auto Reset Trip [50] Comparator 4
[51] Comparator 5 [60] Logic rule 4 [61] Logic rule 5 [83] Broken Belt 13-02 Stop Event [0] False [1] True [2] Running [3] In range [4] On reference
[7] Out of current range
[8] Below I low [9] Above I high [16] Thermal warning [17] Mains out of range
[18] Reversing [19] Warning
[20] Alarm (trip) [21] Alarm (trip lock) [22] Comparator 0
[23] Comparator 1 [24] Comparator 2
[25] Comparator 3 [26] Logic rule 0 [27] Logic rule 1 [28] Logic rule 2 [29] Logic rule 3 [30] SL Time-out 0
[31] SL Time-out 1 [32] SL Time-out 2
[33] Digital input DI18
Appendix Operating Guide
MG07A402 Danfoss A/S © 10/2017 All rights reserved. 73
