[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
*[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-03 Reset SLC
*[0] Do not reset SLC
[1] Reset SLC
13-1* Comparators
13-10 Comparator Operand
*[0] Disabled
[1] Reference %
[2] Feedback %
[3] Motor speed
[4] Motor Current
[6] Motor power
[7] Motor voltage
[12] Analog input AI53
[13] Analog input AI54
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[30] Counter A
[31] Counter B
13-11 Comparator Operator
[0] Less Than (<)
*[1] Approx.Equal (~)
[2] Greater Than (>)
13-12 Comparator Value
-9999 - 9999 *0
13-2* Timers
13-20 SL Controller Timer
0 - 3600 s *0 s
13-4* Logic Rules
13-40 Logic Rule Boolean 1
*[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-41 Logic Rule Operator 1
*[0] Disabled
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
13-42 Logic Rule Boolean 2
Same choices with 13-40
13-43 Logic Rule Operator 2
Same choices with 13-41
13-44 Logic Rule Boolean 3
Same choices with 13-40
13-5* States
13-51 SL Controller Event
*[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-52 SL Controller Action
*[0] Disabled
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[25] Qstop
[26] DC Brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
14-** Special Functions
14-0* Inverter Switching
14-01 Switching Frequency
[0] Ran3
[1] Ran5
[2] 2.0 kHz
[3] 3.0 kHz
[4] 4.0 kHz
[5] 5.0 kHz
[6] 6.0 kHz
[7] 8.0 kHz
[8] 10.0 kHz
[9] 12.0 kHz
[10] 16.0 kHz
14-03 Overmodulation
[0] O
*[1] On
14-07 Dead Time Compensation Level
0 - 100 *Size related
14-08 Damping Gain Factor
0 - 100 % *Size related
14-09 Dead Time Bias Current Level
0 - 100 % *Size related
14-1* Mains On/O
14-10 Mains Failure
*[0] No function
[1] Ctrl. ramp-down
[2] Ctrl. ramp-down, trip
[3] Coasting
[4] Kinetic back-up
[5] Kinetic back-up, trip
[6] Alarm
[7] Kin. back-up, trip w recovery
14-11 Mains Fault Voltage Level
100 - 800 V *Size related
14-12 Response to Mains Imbalance
*[0] Trip
[1] Warning
[2] Disabled
14-15 Kin. Back-up Trip Recovery Level
0 - 500.000 ReferenceFeedbackUnit
*Size related
14-2* Reset Functions
14-20 Reset Mode
*[0] Manual reset
[1] Automatic reset x 1
[2] Automatic reset x 2
[3] Automatic reset x 3
[4] Automatic reset x 4
[5] Automatic reset x 5
[6] Automatic reset x 6
[7] Automatic reset x 7
[8] Automatic reset x 8
[9] Automatic reset x 9
[10] Automatic reset x 10
[11] Automatic reset x 15
[12] Automatic reset x 20
[13] Innite auto reset
[14] Reset at power-up
14-21 Automatic Restart Time
0 - 600 s *10 s
14-22 Operation Mode
*[0] Normal operation
[2] Initialisation
14-24 Trip Delay at Current Limit
0 - 60 s *60 s
14-25 Trip Delay at Torque Limit
0 - 60 s *60 s
14-27 Action At Inverter Fault
[0] Trip
*[1] Warning
14-28 Production Settings
*[0] No action
[1] Service reset
[3] Software Reset
14-29 Service Code
0 - 0xFFFFFFFF *0
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain
0 - 500 % *100 %
14-31 Current Lim Ctrl, Integration Time
0.002 - 2 s *0.020 s
14-32 Current Lim Ctrl, Filter Time
1 - 100 ms *5 ms
14-4* Energy Optimising
14-40 VT Level
40 - 90 % *66 %
14-41 AEO Minimum Magnetisation
40 - 75 % *66 %
14-44 d-axis current optimization for IPM
0 - 200 % *100 %
14-5* Environment
14-51 DC-Link Voltage Compensation
[0] O
*[1] On
14-52 Fan Control
[5] Constant-on mode
[6] Constant-o mode
[7] On-when-Inverter-is-on-else-o Mode
*[8] Variable-speed mode
14-55 Output Filter
*[0] No Filter
[1] Sine-Wave Filter
14-6* Auto Derate
14-61 Function at Inverter Overload
Appendix
VLT
®
Midi Drive FC 280
