Danfoss VLT Midi Drive FC 280

*[0] Trip [1] Derate 14-63 Min Switch Frequency
*[2] 2.0 kHz [3] 3.0 kHz [4] 4.0 kHz [5] 5.0 kHz [6] 6.0 kHz [7] 8.0 kHz [8] 10.0 kHz [9] 12.0 kHz
[10] 16.0 kHz 14-64 Dead Time Compensation Zero Current
Level
*[0] Disabled [1] Enabled 14-65 Speed Derate Dead Time Compen-
sation
20 - 1000 Hz *Size related
14-7* Compatibility 14-70 Compatibility Selections
*[0] No Function
[12] Status Par. VLT2800
14-8* Options 14-88 Option Data Storage
0 - 65535 *0
14-89 Option Detection
*[0] Protect Option Cong.
[1] Enable Option Change 14-9* Fault Settings 14-90 Fault Level
*[3] Trip Lock [4] Trip w. delayed reset
[5] Flystart
15-** Drive Information 15-0* Operating Data 15-00 Operating hours
0 - 0x7f. h *0 h
15-01 Running Hours
0 - 0x7f. h *0 h
15-02 kWh Counter
0 - 2147483647 kWh *0 kWh
15-03 Power Up's
0 - 2147483647 *0
15-04 Over Temp's
0 - 65535 *0
15-05 Over Volt's
0 - 65535 *0
15-06 Reset kWh Counter
*[0] Do not reset [1] Reset counter 15-07 Reset Running Hours Counter *[0] Do not reset [1] Reset counter
15-3* Alarm Log 15-30 Alarm Log: Error Code
0 - 255 *0
15-31 InternalFaultReason
-32767 - 32767 *0
15-4* Drive Identication 15-40 FC Type
0 - 0 *0
15-41 Power Section
0 - 20 *0
15-42 Voltage
0 - 20 *0
15-43 Software Version
0 - 0 *0
15-44 Ordered TypeCode
0 - 41 *0
15-45 Actual Typecode String
0 - 40 *0
15-46 Drive Ordering No
0 - 0 *0
15-48 LCP Id No
0 - 0 *0
15-49 SW ID Control Card
0 - 0 *0
15-50 SW ID Power Card
0 - 0 *0
15-51 Drive Serial Number
0 - 0 *0
15-52 OEM Information
0 - 0 *0
15-53 Power Card Serial Number
0 - 0 *0
15-57 File Version
0 - 255 *0
15-59 Filename
0 - 16 *0
15-6* Option Ident 15-60 Option Mounted
0 - 30 *Size related
15-61 Option SW Version
0 - 20 *Size related
15-70 Option in Slot A
0 - 30 *0
15-71 Slot A Option SW Version
0 - 20 *0
15-9* Parameter Info 15-92 Dened Parameters
0 - 2000 *0
15-97 Application Type
0 - 0xFFFFFFFF *0
15-98 Drive Identication
0 - 56 *0
15-99 Parameter Metadata
0 - 9999 *0
16-** Data Readouts 16-0* General Status 16-00 Control Word
0 - 65535 *0
16-01 Reference [Unit]
-4999 - 4999 ReferenceFeedbackUnit *0 ReferenceFeedbackUnit
16-02 Reference [%]
-200 - 200 % *0 %
16-03 Status Word
0 - 65535 *0
16-05 Main Actual Value [%]
-200 - 200 % *0 %
16-09 Custom Readout
0 - 9999 CustomReadoutUnit *0
CustomReadoutUnit
16-1* Motor Status 16-10 Power [kW]
0 - 1000 kW *0 kW
16-11 Power [hp]
0 - 1000 hp *0 hp
16-12 Motor Voltage
0 - 65535 V *0 V
16-13 Frequency
0 - 6553.5 Hz *0 Hz
16-14 Motor current
0 - 655.35 A *0 A
16-15 Frequency [%]
0 - 6553.5 % *0 %
16-16 Torque [Nm]
-30000 - 30000 Nm *0 Nm
16-17 Speed [RPM]
-30000 - 30000 RPM *0 RPM
16-18 Motor Thermal
0 - 100 % *0 %
16-20 Motor Angle
0 - 65535 *0
16-22 Torque [%]
-200 - 200 % *0 %
16-3* Drive Status 16-30 DC Link Voltage
0 - 65535 V *0 V
16-33 Brake Energy /2 min
0 - 10000 kW *0 kW
16-34 Heatsink Temp.
-128 - 127 °C *0 °C
16-35 Inverter Thermal
0 - 255 % *0 %
16-36 Inv. Nom. Current
0 - 655.35 A *0 A
16-37 Inv. Max. Current
0 - 655.35 A *0 A
16-38 SL Controller State
0 - 20 *0
16-39 Control Card Temp.
0 - 65535 °C *0 °C
16-5* Ref. & Feedb. 16-50 External Reference
-200 - 200 % *0 %
16-52 Feedback[Unit]
-4999 - 4999 ProcessCtrlUnit *0 ProcessCtrlUnit
16-53 Digi Pot Reference
-200 - 200 *0
16-57 Feedback [RPM]
-30000 - 30000 RPM *0 RPM
16-6* Inputs & Outputs 16-60 Digital Input
0 - 4095 *0
16-61 Terminal 53 Setting [1] Voltage mode
[6] Digital input 16-62 Analog input 53
0 - 20 *1
16-63 Terminal 54 Setting
[0] Current mode
[1] Voltage mode 16-64 Analog input 54
0 - 20 *1
16-65 Analog output 42 [mA]
0 - 20 mA *0 mA
16-66 Digital Output
0 - 63 *0
16-67 Pulse input 29 [Hz]
0 - 130000 *0
16-68 Pulse input 33 [Hz]
0 - 130000 *0
16-69 Pulse output 27 [Hz]
0 - 40000 *0
16-71 Relay output
0 - 31 *0
16-72 Counter A
-32768 - 32767 *0
16-73 Counter B
-32768 - 32767 *0
16-74 Prec. Stop Counter
0 - 2147483647 *0
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1
0 - 65535 *0
16-82 Fieldbus REF 1
-32768 - 32767 *0
16-84 Comm. Option STW
0 - 65535 *0
16-85 FC Port CTW 1
0 - 65535 *1084
16-86 FC Port REF 1
-32768 - 32767 *0
16-9* Diagnosis Readouts 16-90 Alarm Word
0 - 0xFFFFFFFFUL *0
16-91 Alarm Word 2
0 - 0xFFFFFFFFUL *0
16-92 Warning Word
0 - 0xFFFFFFFFUL *0
16-93 Warning Word 2
0 - 0xFFFFFFFFUL *0
16-94 Ext. Status Word
0 - 0xFFFFFFFFUL *0
16-95 Ext. Status Word 2
0 - 0xFFFFFFFFUL *0
16-97 Alarm Word 3
0 - 0xFFFFFFFFUL *0
18-** Data Readouts 2 18-9* PID Readouts 18-90 Process PID Error
-200 - 200 % *0 %
18-91 Process PID Output
-200 - 200 % *0 %
18-92 Process PID Clamped Output
-200 - 200 % *0 %
18-93 Process PID Gain Scaled Output
-200 - 200 % *0 %
21-** Ext. Closed Loop 21-0* Ext. CL Autotuning 21-09 Extended PID Enable
*[0] Disabled [1] Enabled Ext CL1 PID
21-1* Ext. CL 1 Ref./Fb.
21-11 Ext. 1 Minimum Reference
-999999.999 - 999999.999 ExtPID1Unit *0 ExtPID1Unit
21-12 Ext. 1 Maximum Reference
-999999.999 - 999999.999 ExtPID1Unit *100 ExtPID1Unit
21-13 Ext. 1 Reference Source
*[0] No function [1] Analog Input 53 [2] Analog Input 54
[7] Frequency input 29 [8] Frequency input 33
21-14 Ext. 1 Feedback Source
*[0] No function [1] Analog Input 53 [2] Analog Input 54 [3] Frequency input 29
[4] Frequency input 33
21-15 Ext. 1 Setpoint
-999999.999 - 999999.999 ExtPID1Unit *0 ExtPID1Unit
21-17 Ext. 1 Reference [Unit]
-999999.999 - 999999.999 ExtPID1Unit *0 ExtPID1Unit
21-18 Ext. 1 Feedback [Unit]
-999999.999 - 999999.999 ExtPID1Unit *0 ExtPID1Unit
21-19 Ext. 1 Output [%]
0 - 100 % *0 %
21-2* Ext. CL 1 PID 21-20 Ext. 1 Normal/Inverse Control *[0] Normal [1] Inverse 21-21 Ext. 1 Proportional Gain
0 - 10 *0.01
21-22 Ext. 1 Integral Time
0.01 - 10000 s *10000 s
21-23 Ext. 1 Dierentation Time
0 - 10 s *0 s
21-24 Ext. 1 Dif. Gain Limit
1 - 50 *5
22-** Appl. Functions 22-0* Miscellaneous 22-02 Sleepmode CL Control Mode *[0] Normal [1] Simplied 22-4* Sleep Mode 22-40 Minimum Run Time
Appendix Operating Guide
MG07A402 Danfoss A/S © 10/2017 All rights reserved. 75
