Danfoss VLT series Quick Guide

195NA407.10
L1
L2
L3
PE
Control cables
Cable insulation stripped
PLC etc.
Mains-supply
Min. 200mm
between control
cable, mains cable
and between mains
motor cable
PLC
Reinforced protective earth
Illustration 1.6 EMC-correct Electrical Installation, FCM 106
NOTE
For North America use metal conduits instead of shielded
cables.
Quick Guide
VLT
®
HVAC Basic Drive Cascade Controller Quick Guide
MG18F402 - VLT
®
is a registered Danfoss trademark 9
1 1

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
