1.3.2 Side-by-Side Installation
The frequency converter can be mounted side-by-side and
requires the clearance above and below for cooling, as
stated in Table 1.4.
Power Clearance
above/below
[mm/inch]
Frame IP class 3x380-480 V
H1 IP20 0.37-1.5 kW/
0.5-2 hp
100/4
H2 IP20 2.2-4 kW/
3-5.4 hp
100/4
H3 IP20 5.5-7.5 kW/
7.5-10 hp
100/4
H4 IP20 11-15 kW/
15-20 hp
100/4
H5 IP20 18.5-22 kW/
25-30 hp
100/4
H6 IP20 30-45 kW/
40-60 hp
200/7.9
H7 IP20 55-75 kW/
100-120 hp
200/7.9
H8 IP20 90 kW/
125 hp
225/8.9
Table 1.4
NOTE
With IP21/Nema Type1 option kit mounted, a distance of
50 mm between the units is required.
Quick Guide
VLT
®
HVAC Basic Drive Cascade Controller Quick Guide
4 MG18F402 - VLT
®
is a registered Danfoss trademark
11
